Introducing a Managed Component for Maintaining Host Routes in Kubernetes

Our new DOKS routing agent is a managed component for configuring static routes on Kubernetes worker nodes. It is a direct response to user feedback on its predecessor, the static route operator, and introduces new features to enhance routing flexibility. Despite being a managed component, the DOKS routing agent is included at no additional cost for users.

Key Features of the DOKS Routing Agent

1. Static Route Management via Custom Resources

The DOKS routing agent enables users to configure IP routes on their Kubernetes worker nodes using a dedicated Kubernetes Custom Resource. This is particularly useful for VPN setups or tunneling egress traffic through specific gateway nodes.

Example Configuration:

apiVersion: networking.doks.digitalocean.com/v1alpha1
kind: Route
metadata:
  name: basic
spec:
  destinations:
    - "1.2.3.4/5"  # Networks to be routed via the specified gateways
  gateways:
    - "10.114.0.3"  # Gateway IP

2. Support for Multiple Gateways and ECMP

The routing agent supports multiple gateways and automatically configures ECMP (Equal-Cost Multi-Path) routing to distribute traffic across them.

Example Configuration:

apiVersion: networking.doks.digitalocean.com/v1alpha1
kind: Route
metadata:
  name: basic
spec:
  destinations:
    - "1.2.3.4/5"
  gateways:
    - "10.114.0.3"
    - "10.114.0.4"

How ECMP Works:

• ECMP distributes traffic across multiple gateways based on a hash of source/destination IP and port.
• If a gateway fails, the Linux kernel stops sending traffic to it.
• The routing agent pings gateways every 30 seconds to detect failures and restore traffic flow when a gateway recovers.
• Note: Ensure that ICMP traffic is allowed on gateways for health checks to function properly.

3. Overriding Default Routes

The routing agent allows users to override default routes without disrupting cluster connectivity—one of the most requested features.

Example Configuration:

apiVersion: networking.doks.digitalocean.com/v1alpha1
kind: Route
metadata:
  name: basic
spec:
  destinations:
    - "0.0.0.0/0"  # Default route
  gateways:
    - "10.114.0.3"
    - "10.114.0.4"

To prevent issues with Kubernetes components, the routing agent ensures that essential control plane endpoints, metadata services, and DNS servers maintain direct connectivity through the worker node Droplet’s default gateway.

4. Node Selection for Routes

Routes can be applied to specific nodes using Kubernetes label selectors, allowing for fine-grained control over network configurations.

Example Configuration:

apiVersion: networking.doks.digitalocean.com/v1alpha1
kind: Route
metadata:
  name: basic
spec:
  destinations:
    - "1.2.3.4/5"
  gateways:
    - "10.114.0.3"
  nodeSelector:
    nodeSelectorTerms:
      - matchExpressions:
          - key: doks.digitalocean.com/node-pool
            operator: In
            values:
              - "worker-pool"

Enabling the DOKS Routing Agent

The routing agent can be enabled or disabled using doctl or the DigitalOcean API.

Example Commands:

doctl kubernetes cluster create --enable-routing-agent ...

doctl kubernetes cluster update --enable-routing-agent ...

For API users, the field structure is:

{
  "name": "prod-cluster-01",
  "region": "nyc3",
  "routing_agent": {
    "enabled": true
  }
}

Usage for Static Egress IP

With the DOKS routing agent and a self-managed VPC gateway Droplet, users can configure static egress IPs, ensuring outbound traffic from Kubernetes workloads originates from a predictable IP address.

Why This Matters:

• Allow-listing: Secure external services by allow-listing known IPs.
• Compliance: Maintain a consistent outbound IP for regulatory requirements.

Coming Soon: Fully Managed NAT Gateway

We’re also working on a fully managed NAT gateway, which will offer a simpler solution for achieving static egress IPs. This feature is on our roadmap and will be available later this year.

Simplify Static Route Management

The DOKS routing agent streamlines static route management in Kubernetes, providing:

• Custom routes using Kubernetes Custom Resources
• Load distribution across multiple gateways with ECMP
• Default route overrides without disrupting cluster connectivity
• Node-specific routing with label selectors

These features are especially useful for VPN setups, custom egress routing, and self-managed VPC gateways.
