Mockito Tutorial

Published on August 3, 2022
author

Pankaj

Mockito Tutorial

Mockito is a java based mocking framework, used in conjunction with other testing frameworks such as JUnit and TestNG. It internally uses Java Reflection API and allows to create objects of a service. A mock object returns a dummy data and avoids external dependencies. It simplifies the development of tests by mocking external dependencies and apply the mocks into the code under test.

Mockito Tutorial

For the Mockito tutorial, we will use JUnit 5 and create some services to mock.

Mockito Maven Dependencies

To implement Mockito based test cases in a project, add the following dependency to the pom.xml file of the project:

<dependency>
     <groupId>org.mockito</groupId>
     <artifactId>mockito-core</artifactId>
     <version>2.19.0</version>
     <scope>test</scope>
</dependency>
<dependency>
     <groupId>org.mockito</groupId>
     <artifactId>mockito-junit-jupiter</artifactId>
     <version>2.19.0</version>
     <scope>test</scope>
</dependency>

Note that mockito-junit-jupiter is required for JUnit 5, if you are using any other testing framework such as JUnit 4 or TestNG then you remove this dependency and include only mockito-core dependency.

Mockito Mock Creation

The Mockito framework allows us to create mock objects using either @Mock annotation or mock() static method.

Mockito mock() Method

The below example shows the usage of mock() method:

package com.journaldev.mockito;

import static org.junit.jupiter.api.Assertions.assertEquals;
import static org.mockito.Mockito.when;

import org.junit.jupiter.api.Test;
import org.mockito.Mockito;

import com.journaldev.AddService;
import com.journaldev.CalcService;

public class CalcService1Test {

	@Test
	void testCalc() {
		System.out.println("**--- Test testCalc executed ---**");

		AddService addService;
		CalcService calcService;

		addService = Mockito.mock(AddService.class);
		calcService = new CalcService(addService);

		int num1 = 11;
		int num2 = 12;
		int expected = 23;

		when(addService.add(num1, num2)).thenReturn(expected);

		int actual = calcService.calc(num1, num2);

		assertEquals(expected, actual);

	}
}

In the above example, we are testing CalcService. Mockito.mock() method is used to create a mock object of AddService class.

Mockito Mock Annotation

The below example shows the usage of @Mock annotation.

package com.journaldev.mockito;

import static org.junit.jupiter.api.Assertions.assertEquals;
import static org.mockito.Mockito.when;

import org.junit.jupiter.api.BeforeEach;
import org.junit.jupiter.api.Test;
import org.mockito.Mock;
import org.mockito.MockitoAnnotations;

import com.journaldev.AddService;
import com.journaldev.CalcService;

public class CalcService2Test {

	CalcService calcService;

	@Mock
	AddService addService;

	@BeforeEach
	public void setup() {
		MockitoAnnotations.initMocks(this);
	}

	@Test
	public void testCalc() {
		System.out.println("**--- Test testCalc executed ---**");

		calcService = new CalcService(addService);

		int num1 = 11;
		int num2 = 12;
		int expected = 23;

		when(addService.add(num1, num2)).thenReturn(expected);

		int actual = calcService.calc(num1, num2);

		assertEquals(expected, actual);

	}
}

Note that we need to call MockitoAnnotations.initMocks(this); to initialize objects annotated with @Mock, @Spy, @Captor, or @InjectMocks.

Mockito Behavior Verification

To add a behavior to the mocked class when() and thenReturn() functions are used. It means that when the mock object (addService) is called for add method with (num1, num2) parameters, then it returns the value stored in the expected variable. Our CalcService class looks like below:

public class CalcService {

	private AddService addService;

	public CalcService(AddService addService) {
		this.addService = addService;
	}

	public int calc(int num1, int num2) {
		System.out.println("**--- CalcService calc executed ---**");
		return addService.add(num1, num2);
	}

}

The CalcService has a dependency on AddService class. It uses the AddService class’s add method to perform its operation. Since we wanted to do unit testing of CalcService class only, we have to mock the AddService instance. The AddService looks like below:

public interface AddService {
	public int add(int num1, int num2);
}
public class AddServiceImpl implements AddService {
	@Override
	public int add(int num1, int num2) {
		System.out.println("**--- AddServiceImpl add executed ---**");
		return num1 + num2;
	}
}

Mockito Verify Interaction

Mockito framework keeps track of all the method calls and their parameters to the mock object. Mockito verify() method on the mock object verifies that a method is called with certain parameters. We can also specify the number of invocation logic, such as the exact number of times, at least specified number of times, less than the specified number of times, etc. We can use VerificationModeFactory for number of invocation times logic. Mockito verify() method checks that a method is called with the right parameters. It does not check the result of a method call like assert method. The below example demonstrates the usage of verify() method:

package com.journaldev.mockito;

import static org.mockito.Mockito.verify;

import java.util.List;

import org.junit.jupiter.api.Test;
import org.mockito.Mockito;
import org.mockito.internal.verification.VerificationModeFactory;

public class VerifyInteractionTest {
	@Test
	public void testMethod() {
		@SuppressWarnings("unchecked")
		List<String> mockedList = Mockito.mock(List.class);

		mockedList.add("first-element");
		mockedList.add("second-element");
		mockedList.add("third-element");
		mockedList.add("third-element");
		mockedList.clear();

		verify(mockedList).add("first-element");
		verify(mockedList).add("second-element");
		verify(mockedList, VerificationModeFactory.times(2)).add("third-element");

		verify(mockedList).clear();
	}

}

Mockito Stub Concrete Class

Using when() - thenReturn() function, we can stub a concrete/implementation class and also a single element of a collection. The non-stubbed elements will contains null in them.

package com.journaldev.mockito;

import static org.mockito.Mockito.mock;
import static org.mockito.Mockito.when;

import java.util.ArrayList;

import org.junit.jupiter.api.Test;
import static org.junit.jupiter.api.Assertions.assertEquals;

public class MockSingleElementTest {
	@SuppressWarnings("unchecked")
	@Test
	public void testMethod() {
		ArrayList mockedList = mock(ArrayList.class);

		when(mockedList.get(0)).thenReturn("first-element");

		System.out.println(mockedList.get(0));
		assertEquals("first-element", mockedList.get(0));

		// "null" gets printed as get(1) is not stubbed
		System.out.println(mockedList.get(1));
	}

}

Mockito Spy

When you call the method of a spied object, the real method will be called, unless a predefined behavior was defined. Using spy we can define behavior by using when() - theReturn() functions or can invoke real implementation.

package com.journaldev.mockito;

import static org.junit.jupiter.api.Assertions.assertEquals;
import static org.mockito.Mockito.spy;
import static org.mockito.Mockito.when;

import java.util.ArrayList;
import java.util.List;

import org.junit.jupiter.api.Test;

public class MockitoSpyTest {

	@Test
	public void testMethod() {
		List<String> list = new ArrayList<>();
		List<String> listSpy = spy(list);

		listSpy.add("first-element");
		System.out.println(listSpy.get(0));

		assertEquals("first-element", listSpy.get(0));
		when(listSpy.get(0)).thenReturn("second-element");
		System.out.println(listSpy.get(0));
		assertEquals("second-element", listSpy.get(0));
	}

}

Conclusion

Mockito is a popular mocking framework for Java unit testing. We can easily mock dependencies using Mockito. Mockito coding style is fluent and similar to JUnit and TestNG frameworks, so its learning curve is very small.

You can download the complete project code from our GitHub Repository.

Thanks for learning with the DigitalOcean Community. Check out our offerings for compute, storage, networking, and managed databases.

Learn more about our products

About the authors
Default avatar
Pankaj

author

While we believe that this content benefits our community, we have not yet thoroughly reviewed it. If you have any suggestions for improvements, please let us know by clicking the “report an issue“ button at the bottom of the tutorial.

Still looking for an answer?

Ask a questionSearch for more help

Was this helpful?

JournalDev
DigitalOcean Employee
DigitalOcean Employee badge
August 29, 2020

This line when(listSpy.get(0)).thenReturn(“second-element”); in last example is not correct. Because listSpy.get(0) will be executed which should not be. doReturn(“second-element”).when(listSpy).get(0) should be used

- Dhiraj

    JournalDev
    DigitalOcean Employee
    DigitalOcean Employee badge
    March 20, 2019

    Could you please provide the output of all the program below the code snippet.that will helpful understand While reading the code itself.

    - Nagarajan

      JournalDev
      DigitalOcean Employee
      DigitalOcean Employee badge
      March 14, 2019

      Hi, can you please tell me and if possible provide some example for equivalent of org.junit.runner.JUnitCore.runClasses in Junit 5?

      - durga

        JournalDev
        DigitalOcean Employee
        DigitalOcean Employee badge
        February 18, 2019

        what is the use of doing this mock test ? it’s like putting some value in a string, and then checking whether the string has the value which I put in at the first place…

        - kishore
