Hello readers. Welcome to our tutorial on debugging and Visualisation in PyTorch. This is, for at least now, is the last part of our PyTorch series start from basic understanding of graphs, all the way to this tutorial.
In this tutorial we will cover PyTorch hooks and how to use them to debug our backward pass, visualise activations and modify gradients.
Hooks in PyTorch are severely under documented for the functionality they bring to the table. Consider them like the the Doctor Fate of the superheroes. Haven’t heard of him? Exactly. That’s the point.
One of the reason I like hooks so much is that they provide you to do things during backpropagation. A hook is like a one of those devices that many heroes leave behind in the villain’s den to get all the information.
You can register a hook on a Tensor
or a nn.Module
. A hook is basically a function that is executed when the either forward
or backward
is called.
When I say forward
, I don’t mean the forward
of a nn.Module
. forward
function here means the forward
function of the torch.Autograd.Function
object that is the grad_fn
of a Tensor. Last line seem gibberish to you? I recommend you to please checkout our article on computation graph in PyTorch. If you are just being lazy, then understand every tensor has a grad_fn
which is the torch.Autograd.Function
object which created the tensor. For example, if a tensor is created by tens = tens1 + tens2
, it’s grad_fn
is AddBackward
. Still doesn’t make sense? You should definitely go back and read this article.
Notice, that a nn.Module
like a nn.Linear
has multiple forward
invocations. It’s output is created by two operations, (Y = W * X + B), addition and multiplication and thus there will be two forward
calls. This can mess things up, and can lead to multiple outputs. We will touch this in more detail later in this article.
PyTorch provides two types of hooks.
A forward hook is executed during the forward pass, while the backward hook is , well, you guessed it, executed when the backward
function is called. Time to remind you again, these are the forward
and backward
functions of an Autograd.Function
object.
These prerequisites will help you understand and effectively utilize hooks in PyTorch for debugging, modifying, or extracting information during model training.
A hook is basically a function, with a very specific signature. When we say a hook is executed, in reality, we are talking about this function being executed.
For tensors, the signature for backward hook is,
hook(grad) -> Tensor or None
There is no forward
hook for a tensor.
grad
is basically the value contained in the grad
attribute of the tensor after backward
is called. The function is not supposed modify it’s argument. It must either return None
or a Tensor which will be used in place of grad
for further gradient computation. We provide an example below.
import torch
a = torch.ones(5)
a.requires_grad = True
b = 2*a
b.retain_grad() # Since b is non-leaf and it's grad will be destroyed otherwise.
c = b.mean()
c.backward()
print(a.grad, b.grad)
# Redo the experiment but with a hook that multiplies b's grad by 2.
a = torch.ones(5)
a.requires_grad = True
b = 2*a
b.retain_grad()
b.register_hook(lambda x: print(x))
b.mean().backward()
print(a.grad, b.grad)
There are several uses of functionality as above.
retain_grad
upon them. Doing the latter can lead to increased memory retention. Hooks provide much cleaner way to aggregate these values.grad
variable of a tensor in a network, you can only access it after the entire backward pass has been done. For example, let us consider what we did above. We multiplied b
’s gradient by 2, and now the subsequent gradient calculations, like those of a
(or any tensor that will depend upon b
for gradient) use the 2 * grad(b) instead of grad(b). In contrast, had we individually updated the parameters after the backward
, we’d have to multiply b.grad
as well as a.grad
(or infact, all tensors that depend on b
for gradient) by 2.a = torch.ones(5)
a.requires_grad = True
b = 2*a
b.retain_grad()
b.mean().backward()
print(a.grad, b.grad)
b.grad *= 2
print(a.grad, b.grad) # a's gradient needs to updated manually
For nn.Module
object, the signature for the hook function,
hook(module, grad_input, grad_output) -> Tensor or None
for the backward hook, and
hook(module, input, output) -> None
for the forward hook.
Before we begin, let me make it clear that I’m not a fan of using hooks on nn.Module
objects. First, because they force us to break abstraction. A nn.Module
is supposed to be a modularised object representing a layer. However, a hook
is subjected a forward
and a backward
, of which there can be an arbitrary number in a nn.Module
object. This requires me to know the internal structure of the modularised object.
For example, a nn.Linear
involves two forward
calls during it’s execution. Multiplication and Addition ( y = w * x + b). This is why the input
to the hook function can be a tuple containing the inputs to two different forward
calls and output
s the output of the forward call.
grad_input
is the gradient of the input of nn.Module
object w.r.t to the loss ( dL / dx, dL / dw, dL / b). grad_output
is the gradient of the output of the nn.Module
object w.r.t to the gradient. These can be pretty ambiguous for the reason of multiple calls inside a nn.Module
object.
Consider the following code.
import torch
import torch.nn as nn
class myNet(nn.Module):
def __init__(self):
super().__init__()
self.conv = nn.Conv2d(3,10,2, stride = 2)
self.relu = nn.ReLU()
self.flatten = lambda x: x.view(-1)
self.fc1 = nn.Linear(160,5)
def forward(self, x):
x = self.relu(self.conv(x))
return self.fc1(self.flatten(x))
net = myNet()
def hook_fn(m, i, o):
print(m)
print("------------Input Grad------------")
for grad in i:
try:
print(grad.shape)
except AttributeError:
print ("None found for Gradient")
print("------------Output Grad------------")
for grad in o:
try:
print(grad.shape)
except AttributeError:
print ("None found for Gradient")
print("\n")
net.conv.register_backward_hook(hook_fn)
net.fc1.register_backward_hook(hook_fn)
inp = torch.randn(1,3,8,8)
out = net(inp)
(1 - out.mean()).backward()
The output produced is.
Linear(in_features=160, out_features=5, bias=True)
------------Input Grad------------
torch.Size([5])
torch.Size([5])
------------Output Grad------------
torch.Size([5])
Conv2d(3, 10, kernel_size=(2, 2), stride=(2, 2))
------------Input Grad------------
None found for Gradient
torch.Size([10, 3, 2, 2])
torch.Size([10])
------------Output Grad------------
torch.Size([1, 10, 4, 4])
In the code above, I use a hook to print the shapes of grad_input
and grad_output
. Now my knowledge about this may be limited, and please do comment if you have a alternative, but for the love of pink floyd, I cannot figure out what grad_input
is supposed to represent what?
In conv2d
you can guess by shape. The grad_input
of size [10, 3, 3, 2]
is the grad of weights. That of [10]
is maybe bias
. But what about grad of input feature maps. None
? Add to that Conv2d
uses im2col
or it’s cousin to flatten an image such that convolutional over the whole image can be done through matrix computation and not looping. Were there any backward
calls there. So in order to get the gradient of x, I’ll have to call the grad_output
of layer just behind it?
The linear
is baffling. Both the grad_inputs
are size [5]
but shouldn’t the weight matrix of the linear layer be 160 x 5
.
For such confusion I’m not a fan of using hooks with nn.Modules
. You could do it for simple things like ReLU, but for complicated things? Not my cup of tea.
So, I’m all up for using hooks on Tensors. Using named_parameters
functions, I’ve been successfully been able to accomplish all my gradient modifying / clipping needs using PyTorch. named_parameters
allows us much much more control over which gradients to tinker with. Let’s just say, I wanna do two things.
import torch
import torch.nn as nn
class myNet(nn.Module):
def __init__(self):
super().__init__()
self.conv = nn.Conv2d(3,10,2, stride = 2)
self.relu = nn.ReLU()
self.flatten = lambda x: x.view(-1)
self.fc1 = nn.Linear(160,5)
def forward(self, x):
x = self.relu(self.conv(x))
x.register_hook(lambda grad : torch.clamp(grad, min = 0)) #No gradient shall be backpropagated
#conv outside less than 0
# print whether there is any negative grad
x.register_hook(lambda grad: print("Gradients less than zero:", bool((grad < 0).any())))
return self.fc1(self.flatten(x))
net = myNet()
for name, param in net.named_parameters():
# if the param is from a linear and is a bias
if "fc" in name and "bias" in name:
param.register_hook(lambda grad: torch.zeros(grad.shape))
out = net(torch.randn(1,3,8,8))
(1 - out).mean().backward()
print("The biases are", net.fc1.bias.grad) #bias grads are zero
The output produced is:
Gradients less than zero: False
The biases are tensor([0., 0., 0., 0., 0.])
If you noticed, the Tensor
doesn’t have a forward hook, while nn.Module
has one, which is executed when a forward
is called. Notwithstanding the issues I already highlighted with attaching hooks to PyTorch, I’ve seen many people use forward hooks to save intermediate feature maps by saving the feature maps to a python variable external to the hook function. Something like this.
visualisation = {}
inp = torch.randn(1,3,8,8)
def hook_fn(m, i, o):
visualisation[m] = o
net = myNet()
for name, layer in net._modules.items():
layer.register_forward_hook(hook_fn)
out = net(inp)
Generally, the output
for a nn.Module
is the output of the last forward
. However, the above functionality can be safely replicated by without use of hooks. Just simply append the intermediate outputs in the forward
function of nn.Module
object to a list. However, it might be a bit problematic to print the intermediate activation of modules inside nn.Sequential
. To get past this, we need to register a hook to children modules of the Sequential but not the to Sequential
itself.
import torch
import torch.nn as nn
class myNet(nn.Module):
def __init__(self):
super().__init__()
self.conv = nn.Conv2d(3,10,2, stride = 2)
self.relu = nn.ReLU()
self.flatten = lambda x: x.view(-1)
self.fc1 = nn.Linear(160,5)
self.seq = nn.Sequential(nn.Linear(5,3), nn.Linear(3,2))
def forward(self, x):
x = self.relu(self.conv(x))
x = self.fc1(self.flatten(x))
x = self.seq(x)
net = myNet()
visualisation = {}
def hook_fn(m, i, o):
visualisation[m] = o
def get_all_layers(net):
for name, layer in net._modules.items():
#If it is a sequential, don't register a hook on it
# but recursively register hook on all it's module children
if isinstance(layer, nn.Sequential):
get_all_layers(layer)
else:
# it's a non sequential. Register a hook
layer.register_forward_hook(hook_fn)
get_all_layers(net)
out = net(torch.randn(1,3,8,8))
# Just to check whether we got all layers
visualisation.keys() #output includes sequential layers
Finally, you can turn this tensors into numpy arrays and plot activations.
That wraps up our discussion on PyTorch, an unreasonable effective tool in visualising and debugging the back pass. Hope this article would help you in solving your bugs much quicker.
