How To Install and Secure phpMyAdmin on Ubuntu 16.04

Published on April 21, 2016 · Updated on February 20, 2018
Default avatar
By Brennen Bearnes
Developer and author at DigitalOcean.
English
How To Install and Secure phpMyAdmin on Ubuntu 16.04
Not using Ubuntu 16.04?Choose a different version or distribution.
Ubuntu 16.04

Introduction

While many users need the functionality of a database management system like MySQL, they may not feel comfortable interacting with the system solely from the MySQL prompt.

phpMyAdmin was created so that users can interact with MySQL through a web interface. In this guide, we’ll discuss how to install and secure phpMyAdmin so that you can safely use it to manage your databases from an Ubuntu 16.04 system.

Prerequisites

Before you get started with this guide, you need to have some basic steps completed.

First, we’ll assume that you are using a non-root user with sudo privileges, as described in steps 1-4 in the initial server setup of Ubuntu 16.04.

We’re also going to assume that you’ve completed a LAMP (Linux, Apache, MySQL, and PHP) installation on your Ubuntu 16.04 server. If this is not completed yet, you can follow this guide on installing a LAMP stack on Ubuntu 16.04.

Finally, there are important security considerations when using software like phpMyAdmin, since it:

  • Communicates directly with your MySQL installation
  • Handles authentication using MySQL credentials
  • Executes and returns results for arbitrary SQL queries

For these reasons, and because it is a widely-deployed PHP application which is frequently targeted for attack, you should never run phpMyAdmin on remote systems over a plain HTTP connection. If you do not have an existing domain configured with an SSL/TLS certificate, you can follow this guide on securing Apache with Let’s Encrypt on Ubuntu 16.04.

Once you are finished with these steps, you’re ready to get started with this guide.

Step One — Install phpMyAdmin

To get started, we will install phpMyAdmin from the default Ubuntu repositories.

We can do this by updating our local package index and then using the apt packaging system to pull down the files and install them on our system:

  1. sudo apt-get update
  2. sudo apt-get install phpmyadmin php-mbstring php-gettext

This will ask you a few questions in order to configure your installation correctly.

Warning: When the first prompt appears, apache2 is highlighted, but not selected. If you do not hit Space to select Apache, the installer will not move the necessary files during installation. Hit Space, Tab, and then Enter to select Apache.

  • For the server selection, choose apache2.
  • Select yes when asked whether to use dbconfig-common to set up the database
  • You will be prompted for your database administrator’s password
  • You will then be asked to choose and confirm a password for the phpMyAdmin application itself

The installation process actually adds the phpMyAdmin Apache configuration file into the /etc/apache2/conf-enabled/ directory, where it is automatically read.

The only thing we need to do is explicitly enable the PHP mcrypt and mbstring extensions, which we can do by typing:

  1. sudo phpenmod mcrypt
  2. sudo phpenmod mbstring

Afterwards, you’ll need to restart Apache for your changes to be recognized:

  1. sudo systemctl restart apache2

You can now access the web interface by visiting your server’s domain name or public IP address followed by /phpmyadmin:

https://domain_name_or_IP/phpmyadmin

phpMyAdmin login screen

You can now log into the interface using the root username and the administrative password you set up during the MySQL installation.

When you log in, you’ll see the user interface, which will look something like this:

phpMyAdmin user interface

Step Two — Secure your phpMyAdmin Instance

We were able to get our phpMyAdmin interface up and running fairly easily. However, we are not done yet. Because of its ubiquity, phpMyAdmin is a popular target for attackers. We should take extra steps to prevent unauthorized access.

One of the easiest way of doing this is to place a gateway in front of the entire application. We can do this using Apache’s built-in .htaccess authentication and authorization functionalities.

Configure Apache to Allow .htaccess Overrides

First, we need to enable the use of .htaccess file overrides by editing our Apache configuration file.

We will edit the linked file that has been placed in our Apache configuration directory:

  1. sudo nano /etc/apache2/conf-available/phpmyadmin.conf

We need to add an AllowOverride All directive within the <Directory /usr/share/phpmyadmin> section of the configuration file, like this:

/etc/apache2/conf-available/phpmyadmin.conf
<Directory /usr/share/phpmyadmin>
    Options FollowSymLinks
    DirectoryIndex index.php
    AllowOverride All
    . . .

When you have added this line, save and close the file.

To implement the changes you made, restart Apache:

  1. sudo systemctl restart apache2

Create an .htaccess File

Now that we have enabled .htaccess use for our application, we need to create one to actually implement some security.

In order for this to be successful, the file must be created within the application directory. We can create the necessary file and open it in our text editor with root privileges by typing:

  1. sudo nano /usr/share/phpmyadmin/.htaccess

Within this file, we need to enter the following information:

/usr/share/phpmyadmin/.htaccess
AuthType Basic
AuthName "Restricted Files"
AuthUserFile /etc/phpmyadmin/.htpasswd
Require valid-user

Let’s go over what each of these lines mean:

  • AuthType Basic: This line specifies the authentication type that we are implementing. This type will implement password authentication using a password file.
  • AuthName: This sets the message for the authentication dialog box. You should keep this generic so that unauthorized users won’t gain any information about what is being protected.
  • AuthUserFile: This sets the location of the password file that will be used for authentication. This should be outside of the directories that are being served. We will create this file shortly.
  • Require valid-user: This specifies that only authenticated users should be given access to this resource. This is what actually stops unauthorized users from entering.

When you are finished, save and close the file.

Create the .htpasswd file for Authentication

The location that we selected for our password file was “/etc/phpmyadmin/.htpasswd”. We can now create this file and pass it an initial user with the htpasswd utility:

  1. sudo htpasswd -c /etc/phpmyadmin/.htpasswd username

You will be prompted to select and confirm a password for the user you are creating. Afterwards, the file is created with the hashed password that you entered.

If you want to enter an additional user, you need to do so without the -c flag, like this:

  1. sudo htpasswd /etc/phpmyadmin/.htpasswd additionaluser

Now, when you access your phpMyAdmin subdirectory, you will be prompted for the additional account name and password that you just configured:

https://domain_name_or_IP/phpmyadmin

phpMyAdmin apache password

After entering the Apache authentication, you’ll be taken to the regular phpMyAdmin authentication page to enter your other credentials. This will add an additional layer of security since phpMyAdmin has suffered from vulnerabilities in the past.

Conclusion

You should now have phpMyAdmin configured and ready to use on your Ubuntu 16.04 server. Using this interface, you can easily create databases, users, tables, etc., and perform the usual operations like deleting and modifying structures and data.


Want to learn more? Join the DigitalOcean Community!

Join our DigitalOcean community of over a million developers for free! Get help and share knowledge in our Questions & Answers section, find tutorials and tools that will help you grow as a developer and scale your project or business, and subscribe to topics of interest.

Sign up
About the authors
Default avatar
Developer and author at DigitalOcean.

Still looking for an answer?

Was this helpful?
10 Comments

This textbox defaults to using Markdown to format your answer.

You can type !ref in this text area to quickly search our full set of tutorials, documentation & marketplace offerings and insert the link!

nano /etc/apache2/apache2.conf

Add the following to the bottom of the file:

phpMyAdmin Configuration

Include /etc/phpmyadmin/apache.conf

I used this tutorial for installing phpmyadmin; but didn’t work after executing all instructions in step 01 I had this error message when trying to access phpmyadmin:

The requested URL /phpmyadmin was not found on this server.

After some research in the Internet I found the solution: I had to add the following instruction in /etc/apache2/apache2.conf

Include /etc/phpmyadmin/apache.conf

then restart my apache2.

Hi,

I dont know what’s happend… but I cant log in phpmyadmin. I tried with user and my pass, root and pass of phpmyadmin. Display this message: #1045 - Access denied for user ‘root’@‘localhost’ (using password: YES)

Hello,

Recently MySQL changed their code so that you could not leave a blank port when installing phpmyadmin so I keep getting an error when I try to install PHP my admin.

"An error occurred while installing the database:

mysql: [ERROR] mysql: Empty value for ‘port’ specified"

https://i.gyazo.com/ae194827faac9ff839e6c64b3c1fd4c8.png

you should make it bigger the part where you mentioned Hit Space, Tab, and then Enter to select Apache. it’s a critical one

Thanks for this - really helpful!

Hello everyone,

Great Tutorial, it’s very clear and to the point. After I have installed phpmyadmin, when clicking on the Databases tab at the top I see No Permission, when I try to create ( New User / Database ), update or grant privileges, I get Access Denied for the user “phpmyadmin”. Turns out I should have been using the root user and the password DO creates automatically, which is found by using sudo cat /root/.digitalocean_password. Thanks to the article https://www.digitalocean.com/community/questions/mysql-root-password my 3 days of suffering has ended.

I needed to add

sudo ln -s /etc/phpmyadmin/apache.conf /etc/apache2/conf-available/phpmyadmin.conf
sudo a2enconf phpmyadmin.conf
sudo service apache2 reload

after installing phpmyadmin

For those of you who didn’t select apache2 in the first step, you may want to re-install.

First uninstall:

apt-get remove phpmyadmin --purge
apt-get autoremove

Then start the installation process again.

I couldn’t load phpmyadmin because I didn’t select apache2 from the beginning. If there is a better way, please share.

The installation process actually adds the phpMyAdmin Apache configuration file into the /etc/apache2/conf-enabled/ directory, where it is automatically read.

Nope, usually he does not.

U must copy: sudo cp /etc/phpmyadmin/apache.conf /etc/apache2/conf-enabled/phpmyadmin.conf Than open it: sudo nano /etc/apache2/conf-enabled/phpmyadmin.conf Add line after “DirectoryIndex index.php”: AllowOverride All

Example: <Directory /usr/share/phpmyadmin> Options FollowSymLinks DirectoryIndex index.php AllowOverride All
