Tutorial

How To Add the gzip Module to Nginx on CentOS 7

Published on March 15, 2016
Default avatar

By Mateusz Papiernik

Software Engineer, CTO @Makimo

How To Add the gzip Module to Nginx on CentOS 7
Not using CentOS 7?Choose a different version or distribution.
CentOS 7

Introduction

How fast a website will load depends on the size of all of the files that have to be downloaded by the browser. Reducing the size of files to be transmitted can make the website not only load faster, but also cheaper to those who have to pay for their bandwidth usage.

gzip is a popular data compression program. You can configure Nginx to use gzip to compress files it serves on the fly. Those files are then decompressed by the browsers that support it upon retrieval with no loss whatsoever, but with the benefit of smaller amount of data being transferred between the web server and browser.

Because of the way compression works in general, but also how gzip works, certain files compress better than others. For example, text files compress very well, often ending up over two times smaller in result. On the other hand, images such as JPEG or PNG files are already compressed by their nature and second compression using gzip yields little or no results. Compressing files use up server resources, so it is best to compress only those files that will reduce its size considerably in result.

In this guide, we’ll discuss how to configure Nginx installed on your CentOS 7 server to utilize gzip compression to reduce the size of content sent to website visitors.

Prerequisites

To follow this tutorial, you will need:

Step 1 — Creating Test Files

In this step, we will create several test files in the default Nginx directory to text gzip’s compression.

To make a decision what kind of file is served over the network, Nginx does not analyze the file contents because it wouldn’t be fast enough. Instead, it just looks up the file extension to determine its MIME type, which denotes the purpose of the file.

Because of this behavior, the contents of the test files is irrelevant. By naming the files appropriately, we can trick Nginx into thinking that one entirely empty file is an image and the another, for example, is a stylesheet.

In our configuration, Nginx will not compress very small files, so we’re are going to create test files that are exactly 1 kilobyte in size. This will allow us to verify whether Nginx uses compression where it should, compressing one type of files and not doing so with the others.

Create a 1 kilobyte file named test.html in the default Nginx directory using truncate. The extension denotes that it’s an HTML page.

  1. sudo truncate -s 1k /usr/share/nginx/html/test.html

Let’s create a few more test files in the same manner: one jpg image file, one css stylesheet, and one js JavaScript file.

  1. sudo truncate -s 1k /usr/share/nginx/html/test.jpg
  2. sudo truncate -s 1k /usr/share/nginx/html/test.css
  3. sudo truncate -s 1k /usr/share/nginx/html/test.js

Step 2 — Checking the Default Behavior

The next step is to check how Nginx behaves in respect to compression on a fresh installation with the files we have just created.

Let’s check if HTML file named test.html is served with compression. The command requests a file from our Nginx server, and specifies that it is fine to serve gzip compressed content by using an HTTP header (Accept-Encoding: gzip).

  1. curl -H "Accept-Encoding: gzip" -I http://localhost/test.html

In response, you should see several HTTP response headers:

Nginx response headers
HTTP/1.1 200 OK
Server: nginx/1.6.3
Date: Fri, 11 Mar 2016 12:53:06 GMT
Content-Type: text/html
Content-Length: 1024
Last-Modified: Fri, 11 Mar 2016 12:48:02 GMT
Connection: keep-alive
ETag: "56e2be82-400"
Accept-Ranges: bytes

In the response, there is no mention of gzip whatsoever. This tells us that gzip compression is not enabled on the server. That’s beause on CentOS 7 the support for gzip is entirely disabled in default Nginx configuration. If the compression was enabled, we would see additional header in the output saying Content-Encoding: gzip.

Not only HTML pages, but also every other file on a fresh installation will be served uncompressed. To verify that, you can request our test image named test.jpg in the same way.

  1. curl -H "Accept-Encoding: gzip" -I http://localhost/test.jpg

The result should be virtually identical as before:

Nginx response headers
HTTP/1.1 200 OK
Server: nginx/1.6.3
Date: Fri, 11 Mar 2016 12:58:03 GMT
Content-Type: image/jpeg
Content-Length: 1024
Last-Modified: Fri, 11 Mar 2016 12:48:05 GMT
Connection: keep-alive
ETag: "56e2be85-400"
Accept-Ranges: bytes

There is no Content-Encoding: gzip header in the output either, which means the file was served without compression.

You can repeat the test with test CSS stylesheet.

  1. curl -H "Accept-Encoding: gzip" -I http://localhost/test.css

Once again, there is no mention of compression in the output.

Nginx response headers for CSS file
HTTP/1.1 200 OK
Server: nginx/1.6.3
Date: Fri, 11 Mar 2016 12:59:04 GMT
Content-Type: text/css
Content-Length: 1024
Last-Modified: Fri, 11 Mar 2016 12:48:05 GMT
Connection: keep-alive
ETag: "56e2be85-400"
Accept-Ranges: bytes

Step 3 — Enabling and Configuring Nginx’s gzip Module

The next step is to configure Nginx to to enable compression for all file formats that can benefit from compression.

The gzip module is a core module in Nginx, which means it is already installed but must be enabled and configured. In a fresh Nginx installation on CentOS 7, all files with the .conf extension from from the /etc/nginx/conf.d directory are automatically loaded. This allows for easy configuration of additional modules.

To enable the Nginx gzip module, create the configuration file named gzip.conf using nano or your favorite text editor.

  1. sudo nano /etc/nginx/conf.d/gzip.conf

Paste in the following contents.

/etc/nginx/conf.d/gzip.conf
##
# `gzip` Settings
#
#
gzip on;
gzip_disable "msie6";

gzip_vary on;
gzip_proxied any;
gzip_comp_level 6;
gzip_http_version 1.1;
gzip_min_length 256;
gzip_types text/plain text/css application/json application/x-javascript text/xml application/xml application/xml+rss text/javascript application/javascript application/vnd.ms-fontobject application/x-font-ttf font/opentype image/svg+xml image/x-icon;

Save and close the file to exit.

Let’s walk through the configuration settings applied here:

  • gzip on directive enables the Gzip compression.

  • gzip_disable "msie6" excludes Internet Explorer 6 from the browsers that will receive compressed files, because IE6 does not support gzip at all.

  • gzip_vary and gzip_proxied settings make sure that proxy servers between the browser and the server will recognize compression correctly.

  • gzip_comp_level 6 sets how much files will be compressed. The higher the number, the higher the compression level and the resources usage. 6 is a reasonable middle ground.

  • gzip_http_version 1.1 is used to limit gzip compression to browsers supporting the HTTP/1.1 protocol. If the browser does not support it, there is a good chance it does not support gzip either.

  • gzip_min_length 256 tells Nginx not to compress files smaller than 256 bytes. Very small files barely benefit from compression.

  • gzip_types lists all of the MIME types that will be compressed. In this case, the list includes HTML pages, CSS stylesheets, Javascript and JSON files, XML files, icons, SVG images, and web fonts.

To enable the new configuration, restart Nginx.

  1. sudo systemctl restart nginx

Step 4 — Verifying the New Configuration

The next step is to check whether changes to the configuration have worked as expected.

We can test this just like we did in step 2, by using curl on each of the test files and examining the output for the Content-Encoding: gzip header.

  1. curl -H "Accept-Encoding: gzip" -I http://localhost/test.html

In response, you should see Content-Encoding: gzip header that was not there before:

Nginx response headers
HTTP/1.1 200 OK
Server: nginx/1.6.3
Date: Fri, 11 Mar 2016 13:19:16 GMT
Content-Type: text/html
Last-Modified: Fri, 11 Mar 2016 12:48:02 GMT
Connection: keep-alive
Vary: Accept-Encoding
Content-Encoding: gzip

You can test all other files the same way:

  1. curl -H "Accept-Encoding: gzip" -I http://localhost/test.jpg
  2. curl -H "Accept-Encoding: gzip" -I http://localhost/test.css
  3. curl -H "Accept-Encoding: gzip" -I http://localhost/test.js

Now only test.jpg, which is an image file, should stay uncompressed. In both other examples, you should be able to find Content-Encoding: gzip header in the output.

If that is the case, you have configured gzip compression in Nginx successfully!

Conclusion

Changing Nginx configuration to fully use gzip compression is easy, but the benefits can be immense. Not only visitors with limited bandwidth will receive the site faster but also Google will be happy about the site loading faster. Speed is gaining traction as an important part of modern web and using gzip is one big step to improve it.

Thanks for learning with the DigitalOcean Community. Check out our offerings for compute, storage, networking, and managed databases.

Learn more about us


About the authors
Default avatar

Software Engineer, CTO @Makimo

Creating bespoke software ◦ CTO & co-founder at Makimo. I’m a software enginner & a geek. I like making impossible things possible. And I need tea.


Default avatar

staff technical writer

hi! i write do.co/docs now, but i used to be the senior tech editor publishing tutorials here in the community.


Still looking for an answer?

Ask a questionSearch for more help

Was this helpful?

2 Comments


This textbox defaults to using Markdown to format your answer.

You can type !ref in this text area to quickly search our full set of tutorials, documentation & marketplace offerings and insert the link!

Great guide!

Reading your instructions for Step 3 are somewhat confusing if taken literally: right after creating “/etc/nginx/conf.d/gzip.conf”, the code label for the instruction to paste in the following contents shows “/etc/nginx/nginx.conf”. I believe this should instead be “/etc/nginx/conf.d/gzip.conf”, the file we just created.

And then for good measure you could mention to make sure /etc/nginx/nginx.conf has the line “include /etc/nginx/conf.d/*.conf;” in it (to auto-include the gzip.conf and others that may be in there.

Thanks!

Your settings for images is wrong sorry to say :(
