This tutorial will show you how to create a High Availability HAProxy load balancer setup on DigitalOcean, with the support of a Reserved IP and the Corosync/Pacemaker cluster stack. The HAProxy load balancers will each be configured to split traffic between two backend application servers. If the primary load balancer goes down, the Reserved IP will be moved to the second load balancer automatically, allowing service to resume.
Note: DigitalOcean Load Balancers are a fully-managed, highly available load balancing service. The Load Balancer service can fill the same role as the manual high availability setup described here. Follow our guide on setting up Load Balancers if you wish to evaluate that option.
In order to complete this guide, you will need to have completed the How To Create a High Availability Setup with Corosync, Pacemaker, and Reserved IPs on Ubuntu 14.04 tutorial (you should skip the optional Add Nginx Resource section). This will leave you with two Droplets, which we’ll refer to as primary and secondary, with a Reserved IP that can transition between them. Collectively, we’ll refer to these servers as load balancers. These are the Droplets where we’ll install a load balancer, HAProxy.
You will also need to be able to create two additional Ubuntu 14.04 Droplets in the same datacenter, with Private Networking enabled, to demonstrate that the HA load balancer setup works. These are the servers that will be load balanced by HAProxy. We will refer to these application servers, which we will install Nginx on, as app-1 and app-2. If you already have application servers that you want to load balance, feel free to use those instead.
On each of these servers, you will need a non-root user configured with sudo
access. You can follow our Ubuntu 14.04 initial server setup guide to learn how to set up these users.
The first step is to create two Ubuntu Droplets, with Private Networking enabled, in the same datacenter as your load balancers, which will act as the app-1 and app-2 servers described above. We will install Nginx on both Droplets and replace their index pages with information that uniquely identifies them. This will allow us a simple way to demonstrate that the HA load balancer setup is working. If you already have application servers that you want to load balance, feel free to adapt the appropriate parts of this tutorial to make that work (and skip any parts that are irrelevant to your setup).
If you want to follow the example setup, create two Ubuntu 14.04 Droplets, app-1 and app-2, and use this bash script as the user data:
#!/bin/bash
apt-get -y update
apt-get -y install nginx
export HOSTNAME=$(curl -s http://169.254.169.254/metadata/v1/hostname)
export PUBLIC_IPV4=$(curl -s http://169.254.169.254/metadata/v1/interfaces/public/0/ipv4/address)
echo Droplet: $HOSTNAME, IP Address: $PUBLIC_IPV4 > /usr/share/nginx/html/index.html
This user data will install Nginx and replace the contents of index.html with the droplet’s hostname and public IP address (by referencing the Metadata service). Accessing either Droplet will show a basic webpage with the Droplet hostname and public IP address, which will be useful for testing which app server the load balancers are directing traffic to.
Before we begin the actual configuration of our infrastructure components, it is best to gather some information about each of your servers.
To complete this guide, you will need to have the following information about your servers:
The easiest way to find your Droplet’s private IP address is to use curl
to grab the private IP address from the DigitalOcean metadata service. This command should be run from within your Droplets. On each Droplet, type:
- curl 169.254.169.254/metadata/v1/interfaces/private/0/ipv4/address && echo
The correct IP address should be printed in the terminal window:
Private IP address:10.132.20.236
Perform this step on all four Droplets, and copy the Private IP addresses somewhere that you can easily reference.
The anchor IP is the local private IP address that the Reserved IP will bind to when attached to a DigitalOcean server. It is simply an alias for the regular eth0
address, implemented at the hypervisor level.
The easiest, least error-prone way of grabbing this value is straight from the DigitalOcean metadata service. Using curl
, you can reach out to this endpoint on each of your servers by typing:
- curl 169.254.169.254/metadata/v1/interfaces/public/0/anchor_ipv4/address && echo
The anchor IP will be printed on its own line:
Output10.17.1.18
Perform this step on both of your load balancer Droplets, and copy the anchor IP addresses somewhere that you can easily reference.
After gathering the data above, we can move on to configuring our services.
Note
In this setup, the software selected for the web server layer is fairly interchangeable. This guide will use Nginx because it is generic and rather easy to configure. If you are more comfortable with Apache or a (production-capable) language-specific web server, feel free to use that instead. HAProxy will simply pass client requests to the backend web servers which can handle the requests similarly to how it would handle direct client connections.
We will start off by setting up our backend app servers. Both of these servers will simply serve their name and public IP address; in a real setup, these servers would serve identical content. They will only accept web connections over their private IP addresses. This will help ensure that traffic is directed exclusively through one of the two HAProxy servers we will be configuring later.
Setting up app servers behind a load balancer allows us to distribute the request burden among some number identical app servers. As our traffic needs change, we can easily scale to meet the new demands by adding or removing app servers from this tier.
If you’re following the example, and you used the provided user data when creating your app servers, your servers will already have Nginx installed. The next step is to make a few configuration changes.
We want to configure Nginx to only listen for requests on the private IP address of the server. Furthermore, we will only serve requests coming from the private IP addresses of our two load balancers. This will force users to access your app servers through your load balancers (which we will configure to be accessible only via the Reserved IP address).
To make these changes, open the default Nginx server block file on each of your app servers:
- sudo vi /etc/nginx/sites-available/default
To start, we will modify the listen
directives. Change the listen
directive to listen to the current app server’s private IP address on port 80. Delete the extra listen
line. It should look something like this:
server {
listen app_server_private_IP:80;
. . .
Directly below the listen
directive, we will set up two allow
directives to permit traffic originating from the private IP addresses of our two load balancers. We will follow this up with a deny all
rule to forbid all other traffic:
allow load_balancer_1_private_IP;
allow load_balancer_2_private_IP;
deny all;
Save and close the files when you are finished.
Test that the changes that you made represent valid Nginx syntax by typing:
- sudo nginx -t
If no problems were reported, restart the Nginx daemon by typing:
- sudo service nginx restart
Remember to perform all of these steps (with the appropriate app server private IP addresses) on both app servers.
To test that your app servers are restricted correctly, you can make requests using curl
from various locations.
On your app servers themselves, you can try a simple request of the local content by typing:
- curl 127.0.0.1
Because of the restrictions we set in place in our Nginx server block files, this request will actually be denied:
Outputcurl: (7) Failed to connect to 127.0.0.1 port 80: Connection refused
This is expected and reflects the behavior that we were attempting to implement.
Now, from either of the load balancers, we can make a request for either of our app server’s public IP address:
- curl web_server_public_IP
Once again, this should fail. The app servers are not listening on the public interface and furthermore, when using the public IP address, our app servers would not see the allowed private IP addresses in the request from our load balancers:
Outputcurl: (7) Failed to connect to app_server_public_IP port 80: Connection refused
However, if we modify the call to make the request using the app server’s private IP address, it should work correctly:
- curl app_server_private_IP
The Nginx index.html
page should be returned. If you used the example user data, the page should contain the name and public IP address of the app server being accessed:
app server index.htmlDroplet: app-1, IP Address: 159.203.130.34
Test this from both load balancers to both app servers. Each request for the private IP address should succeed while each request made to the public addresses should fail.
Once the above behavior is demonstrated, we can move on. Our backend app server configuration is now complete.
By following the prerequisite HA Setup with Corosync, Pacemaker, and Reserved IPs tutorial, your load balancer servers will have Nginx installed. Because we’re going to use HAProxy as the reverse proxy load balancer, we should delete Nginx and any associated cluster resources.
If you added an Nginx cluster resource while following the prerequisite tutorial, stop and delete the Nginx
resource with these commands on one of your load balancers:
- sudo crm resource stop Nginx
- sudo crm configure delete Nginx
This should also delete any cluster settings that depend on the Nginx
resource. For example, if you created a clone
or colocation
that references the Nginx
resource, they will also be deleted.
Now we’re ready to uninstall Nginx on both of the load balancer servers.
First, stop the Nginx service:
- sudo service nginx stop
Then purge the package with this command:
- sudo apt-get purge nginx
You may also want to delete the Nginx configuration files:
- sudo rm -r /etc/nginx
Now we’re ready to install and configure HAProxy.
Next, we will set up the HAProxy load balancers. These will each sit in front of our web servers and split requests between the two backend app servers. These load balancers will be completely redundant, in an active-passive configuration; only one will receive traffic at any given time.
The HAProxy configuration will pass requests to both of the web servers. The load balancers will listen for requests on their anchor IP address. As mentioned earlier, this is the IP address that the Reserved IP address will bind to when attached to the Droplet. This ensures that only traffic originating from the Reserved IP address will be forwarded.
This section needs to be performed on both load balancer servers.
We will install HAProxy 1.6, which is not in the default Ubuntu repositories. However, we can still use a package manager to install HAProxy 1.6 if we use a PPA, with this command:
- sudo add-apt-repository ppa:vbernat/haproxy-1.6
Update the local package index on your load balancers and install HAProxy by typing:
- sudo apt-get update
- sudo apt-get install haproxy
HAProxy is now installed, but we need to configure it now.
Open the main HAProxy configuration file:
- sudo vi /etc/haproxy/haproxy.cfg
Find the defaults
section, and add the two following lines under it:
option forwardfor
option http-server-close
The forwardfor option sets HAProxy to add X-Forwarded-For
headers to each request—which is useful if you want your app servers to know which IP address originally sent a request—and the http-server-close option reduces latency between HAProxy and your users by closing connections but maintaining keep-alives.
Next, at the end of the file, we need to define our frontend configuration. This will dictate how HAProxy listens for incoming connections. We will bind HAProxy to the load balancer anchor IP address. This will allow it to listen for traffic originating from the Reserved IP address. We will call our frontend “http” for simplicity. We will also specify a default backend, app_pool
, to pass traffic to (which we will be configuring in a moment):
frontend http
bind load_balancer_anchor_IP:80
default_backend app_pool
Note: The anchor IP is the only part of the HAProxy configuration that should differ between the load balancer servers. That is, be sure to specify the anchor IP of the load balancer server that you are currently working on.
Next, we can define the backend configuration. This will specify the downstream locations where HAProxy will pass the traffic it receives. In our case, this will be the private IP addresses of both of the Nginx app servers we configured:
backend app_pool
server app-1 app_server_1_private_IP:80 check
server app-2 app_server_2_private_IP:80 check
When you are finished making the above changes, save and exit the file.
Check that the configuration changes we made represent valid HAProxy syntax by typing:
- sudo haproxy -f /etc/haproxy/haproxy.cfg -c
If no errors were reported, restart your service by typing:
- sudo service haproxy restart
Again, be sure to perform all of the steps in this section on both load balancer servers.
We can make sure our configuration is valid by testing with curl
again.
From the load balancer servers, try to request the local host, the load balancer’s own public IP address, or the server’s own private IP address:
- curl 127.0.0.1
- curl load_balancer_public_IP
- curl load_balancer_private_IP
These should all fail with messages that look similar to this:
Outputcurl: (7) Failed to connect to IP_address port 80: Connection refused
However, if you make a request to the load balancer’s anchor IP address, it should complete successfully:
- curl load_balancer_anchor_IP
You should see the Nginx index.html
page of one of the app servers:
app server index.htmlDroplet: app-1, IP Address: app1_IP_address
Perform the same curl request again:
- curl load_balancer_anchor_IP
You should see the index.html
page of the other app server, because HAProxy uses round-robin load balancing by default:
app server index.htmlDroplet: app-2, IP Address: app2_IP_address
If this behavior matches that of your system, then your load balancers are configured correctly; you have successfully tested that your load balancer servers are balancing traffic between both backend app servers. Also, your Reserved IP should already be assigned to one of the load balancer servers, as that was set up in the prerequisite HA Setup with Corosync, Pacemaker, and Reserved IPs tutorial.
At this point, you have a basic, host-level failover in place but we can improve the setup by adding HAProxy as a cluster resource. Doing so will allow your cluster to ensure that HAProxy is running on the server that your Reserved IP is assigned to. If Pacemaker detects that HAProxy isn’t running, it can restart the service or assign the Reserved IP to the other node (that should be running HAProxy).
Pacemaker allows the addition of OCF resource agents by placing them in a specific directory.
On both load balancer servers, download the HAProxy OCF resource agent with these commands:
- cd /usr/lib/ocf/resource.d/heartbeat
- sudo curl -O https://raw.githubusercontent.com/thisismitch/cluster-agents/master/haproxy
On both load balancer servers, make it executable:
- sudo chmod +x haproxy
Feel free to review the contents of the resource before continuing. It is a shell script that can be used to manage the HAProxy service.
Now we can use the HAProxy OCF resource agent to define our haproxy
cluster resource.
With our HAProxy OCF resource agent installed, we can now configure an haproxy
resource that will allow the cluster to manage HAProxy.
On either load balancer server, create the haproxy
primitive resource with this command:
- sudo crm configure primitive haproxy ocf:heartbeat:haproxy op monitor interval=15s
The specified resource tells the cluster to monitor HAProxy every 15 seconds, and to restart it if it becomes unavailable.
Check the status of your cluster resources by using sudo crm_mon
or sudo crm status
:
crm_mon:...
Online: [ primary secondary ]
FloatIP (ocf::digitalocean:floatip): Started primary
Nginx (ocf::heartbeat:nginx): Started secondary
Unfortunately, Pacemaker might decide to start the haproxy
and FloatIP
resources on separate nodes because we have not defined any resource constraints. This is a problem because the Reserved IP might be pointing to one Droplet while the HAProxy service is running on the other Droplet. Accessing the Reserved IP will point you to a server that is not running the service that should be highly available.
To resolve this issue, we’ll create a clone resource, which specifies that an existing primitive resource should be started on multiple nodes.
Create a clone of the haproxy
resource called “haproxy-clone” with this command:
- sudo crm configure clone haproxy-clone haproxy
The cluster status should now look something like this:
crm_mon:Online: [ primary secondary ]
FloatIP (ocf::digitalocean:floatip): Started primary
Clone Set: haproxy-clone [Nginx]
Started: [ primary secondary ]
As you can see, the clone resource, haproxy-clone
, is now started on both of our nodes.
The last step is to configure a colocation restraint, to specify that the FloatIP
resource should run on a node with an active haproxy-clone
resource. To create a colocation restraint called “FloatIP-haproxy”, use this command:
- sudo crm configure colocation FloatIP-haproxy inf: FloatIP haproxy-clone
You won’t see any difference in the crm status output, but you can see that the colocation resource was created with this command:
- sudo crm configure show
Now, both of your servers should have HAProxy running, while only one of them, has the FloatIP resource running.
Try stopping the HAProxy service on either load balancer server:
- sudo service haproxy stop
You will notice that it will start up again sometime within the next 15 seconds.
Next, we’ll test your HA setup by rebooting your active load balancer server (the one that the FloatIP
resource is currently “started” on).
With your new High Availability HAProxy setup, you will want test that everything works as intended.
In order to visualize the transition between the load balancers better, we can monitor the app server Nginx logs during the transition.
Since information about which proxy server is being used is not returned to the client, the best place to view the logs is from the actual backend web servers. Each of these servers should maintain logs about which clients request assets. From the Nginx service’s perspective, the client is the load balancer that makes requests on behalf of the real client.
While performing the upcoming tests, you might want to look at the real-time status of the cluster nodes and resources. You can do so with this command, on either load balancer server (as long as it is running):
- sudo crm_mon
The output should look something like this:
crm_mon output:Last updated: Thu Nov 5 13:51:41 2015
Last change: Thu Nov 5 13:51:27 2015 via cibadmin on primary
Stack: corosync
Current DC: secondary (2) - partition with quorum
Version: 1.1.10-42f2063
2 Nodes configured
3 Resources configured
Online: [ primary secondary ]
FloatIP (ocf::digitalocean:floatip): Started primary
Clone Set: haproxy-clone [haproxy]
Started: [ primary secondary ]
This will show you which load balancer nodes are online, and which nodes the FloatIP
and haproxy
resources are started on.
Note that the node that the FloatIP
resource is Started
on, primary in the above example, is the load balancer server that the Reserved IP is currently assigned to. We will refer to this server as the active load balancer server.
On your local machine, we will request the web content at the Reserved IP address once every 2 seconds. This will allow us to easily see the how the active load balancer is handling incoming traffic. That is, we will see which backend app servers it is sending traffic to. In your local terminal, enter this command:
- while true; do curl reserved_IP_address; sleep 2; done
Every two seconds, you should see a response from one of the backend app servers. It will probably alternate between app-1 and app-2 because HAProxy’s default balance algorithm, which we haven’t specified, is set to round-robin. So, your terminal should show something like this:
[secondary_label curl loop output:
Droplet: app-1, IP Address: app_1_IP_address
Droplet: app-2, IP Address: app_2_IP_address
...
Keep this terminal window open so that requests are continually sent to your servers. They will be helpful in our next testing steps.
On each of our backend app servers, we can tail
the /var/log/nginx/access.log
location. This will show each request made to the server. Since our load balancers split traffic evenly using a round-robin rotation, each backend app server should see about half of the requests made.
The client address is the very first field in the access log, so it will be easy to find. Run the following on both of your Nginx app servers (in separate terminal windows):
- sudo tail -f /var/log/nginx/access.log
The first field should show private IP address of your active load balancer server, every four seconds (we’ll assume it’s the primary load balancer, but it could be the secondary one in your case):
Output. . .
primary_loadbalancer_IP - - [05/Nov/2015:14:26:37 -0500] "GET / HTTP/1.1" 200 43 "-" "curl/7.43.0"
primary_loadbalancer_IP - - [05/Nov/2015:14:26:37 -0500] "GET / HTTP/1.1" 200 43 "-" "curl/7.43.0"
. . .
Keep the tail
command running on both of your app servers.
Now, let’s reboot the primary load balancer, to make sure that the Reserved IP failover works:
- sudo reboot
Now pay attention to the Nginx access logs on both of your app servers. You should notice that, after the Reserved IP failover occurs, the access logs show that the app servers are being accessed by a different IP address than before. The logs should indicate that the secondary load balancer server is sending the requests:
Output. . .
secondary_loadbalancer_IP - - [05/Nov/2015:14:27:37 -0500] "GET / HTTP/1.1" 200 43 "-" "curl/7.43.0"
secondary_loadbalancer_IP - - [05/Nov/2015:14:27:37 -0500] "GET / HTTP/1.1" 200 43 "-" "curl/7.43.0"
. . .
This shows that the failure of the primary load balancer was detected, and the Reserved IP was reassigned to the secondary load balancer successfully.
You may also want to check the output of your local terminal (which is accessing the Reserved IP every two seconds) to verify that the secondary load balancer is sending requests to both backend app servers:
[secondary_label curl loop output:
Droplet: app-1, IP Address: app_1_IP_address
Droplet: app-2, IP Address: app_2_IP_address
...
You may also try the failover in the other direction, once the other load balancer is online again.
As you have seen, the Nginx access logs show that all client requests are from the private IP address of the current load balancer, instead of the actual IP address of the client that originally made the request (i.e. your local machine). It is often useful to log the IP address of the original requestor, instead of the load balancer server. This is easily achieved by making a few changes to the Nginx configuration on all of your backend app servers.
On both app servers, open the nginx.conf
file in an editor:
- sudo vi /etc/nginx/nginx.conf
Find the “Logging Settings” section (within the http
block), and add the following line:
log_format haproxy_log 'ProxyIP: $remote_addr - ClientIP: $http_x_forwarded_for - $remote_user [$time_local] ' '"$request" $status $body_bytes_sent "$http_referer" ' '"$http_user_agent"';
Save and exit. This specifies a new log format called haproxy_log
, which adds the $http_x_forwarded_for
value—the IP address of the client that made the original request—to the default access log entries. We also are including $remote_addr
, which is the IP address of the reverse proxy load balancer (i.e. the active load balancer server).
Next, to put this new log format to use, we need to add a line to our default server block.
On both app servers, open the default
server configuration:
- sudo vi /etc/nginx/sites-available/default
Within the server
block (right below the listen
directive is a good place), add the following line:
access_log /var/log/nginx/access.log haproxy_log;
Save and exit. This tells Nginx to write its access logs using the haproxy_log
log format that we recently created.
On both app servers, restart Nginx to put the changes into effect:
- sudo service nginx restart
Now your Nginx access logs should contain the actual IP addresses of the clients making requests. Verify this by tailing the logs of your app servers, as we did in the previous section. The log entries should look something like this:
New Nginx access logs:. . .
ProxyIP: load_balancer_private_IP - ClientIP: local_machine_IP - - [05/Nov/2015:15:05:53 -0500] "GET / HTTP/1.1" 200 43 "-" "curl/7.43.0"
. . .
If your logs look good, you’re all set!
In this guide, we walked through the complete process of setting up a highly available, load balanced infrastructure. This configuration works well because the active HAProxy server can distribute the load to the pool of app servers on the backend. You can easily scale this pool as your demand grows or shrinks.
The Reserved IP and Corosync/Pacemaker configuration eliminates the single point of failure at the load balancing layer, allowing your service to continue functioning even when the primary load balancer completely fails. This configuration is fairly flexible and can be adapted to your own application environment by setting up your preferred application stack behind the HAProxy servers.
Thanks for learning with the DigitalOcean Community. Check out our offerings for compute, storage, networking, and managed databases.
This textbox defaults to using Markdown to format your answer.
You can type !ref in this text area to quickly search our full set of tutorials, documentation & marketplace offerings and insert the link!
Sign up for Infrastructure as a Newsletter.
Working on improving health and education, reducing inequality, and spurring economic growth? We'd like to help.
Get paid to write technical tutorials and select a tech-focused charity to receive a matching donation.
Very uncomplete tutorial, the FloatIP crm resource just appears in the crm out of nowhere and no mention of corosync and communication ring(s) setup which is crucial for this to even start working. No mention of quorum and making it work with 2 nodes, split brain and fencing which is a must in production setup. Very dangerous tutorial that makes people think this is very simple to setup and manage.
and what do you when network disconnect? how application handle?
what package/app who handle this high availability?
This comment has been deleted
Thanks heaps for tutorial! I tried to get gluster to work with this setup (followed the gluster part of this tutorial: https://www.digitalocean.com/community/tutorials/how-to-create-a-redundant-storage-pool-using-glusterfs-on-ubuntu-servers). I keep getting the following error when trying peer probe though: peer probe: failed: Probe returned with Transport endpoint is not connected Am I missing a step or is this setup not compatible with gluster?
Can you tell how to auto deploy new droplets in HAproxy after certain threshold?
Hi Mitchel,
Thanks for the tutorial. I have tried it successfully on my droplets to create a passthrough API and still have one more problem left. I need to make sure that the outbound HTTP requests coming from the app server are using the floating IP as their source address. Do you have any ideas of how to achieve this?
Regards Adi
Hi Mitchel, Thanks for the awesome tutorial. I was wondering about that cool diagram, Can you share how did you create it. Specially the animated part :)
Regards Farhad
