How To Create a High Availability Setup with Corosync, Pacemaker, and Reserved IPs on Ubuntu 14.04

How To Create a High Availability Setup with Corosync, Pacemaker, and Reserved IPs on Ubuntu 14.04

Introduction

This tutorial will demonstrate how you can use Corosync and Pacemaker with a Reserved IP to create a high availability (HA) server infrastructure on DigitalOcean.

Corosync is an open source program that provides cluster membership and messaging capabilities, often referred to as the messaging layer, to client servers. Pacemaker is an open source cluster resource manager (CRM), a system that coordinates resources and services that are managed and made highly available by a cluster. In essence, Corosync enables servers to communicate as a cluster, while Pacemaker provides the ability to control how the cluster behaves.

Goal

When completed, the HA setup will consist of two Ubuntu 14.04 servers in an active/passive configuration. This will be accomplished by pointing a Reserved IP, which is how your users will access your web service, to point to the primary (active) server unless a failure is detected. In the event that Pacemaker detects that the primary server is unavailable, the secondary (passive) server will automatically run a script that will reassign the Reserved IP to itself via the DigitalOcean API. Thus, subsequent network traffic to the Reserved IP will be directed to your secondary server, which will act as the active server and process the incoming traffic.

This diagram demonstrates the concept of the described setup:

Active/passive Diagram

Note: This tutorial only covers setting up active/passive high availability at the gateway level. That is, it includes the Reserved IP, and the load balancer servers—Primary and Secondary. Furthermore, for demonstration purposes, instead of configuring reverse-proxy load balancers on each server, we will simply configure them to respond with their respective hostname and public IP address.

To achieve this goal, we will follow these steps:

  • Create 2 Droplets that will receive traffic
  • Create Reserved IP and assign it to one of the Droplets
  • Install and configure Corosync
  • Install and configure Pacemaker
  • Configure Reserved IP Reassignment Cluster Resource
  • Test failover
  • Configure Nginx Cluster Resource

Prerequisites

In order to automate the Reserved IP reassignment, we must use the DigitalOcean API. This means that you need to generate a Personal Access Token (PAT), which is an API token that can be used to authenticate to your DigitalOcean account, with read and write access by following the How To Generate a Personal Access Token section of the API tutorial. Your PAT will be used in a script that will be added to both servers in your cluster, so be sure to keep it somewhere safe—as it allows full access to your DigitalOcean account—for reference.

In addition to the API, this tutorial utilizes the following DigitalOcean features:

Please read the linked tutorials if you want to learn more about them.

Create Droplets

The first step is to create two Ubuntu Droplets, with Private Networking enabled, in the same datacenter, which will act as the primary and secondary servers described above. In our example setup, we will name them “primary” and “secondary” for easy reference. We will install Nginx on both Droplets and replace their index pages with information that uniquely identifies them. This will allow us a simple way to demonstrate that the HA setup is working. For a real setup, your servers should run the web server or load balancer of your choice, such as Nginx or HAProxy.

Create two Ubuntu 14.04 Droplets, primary and secondary. If you want to follow the example setup, use this bash script as the user data:

Example User Data
#!/bin/bash

apt-get -y update
apt-get -y install nginx
export HOSTNAME=$(curl -s http://169.254.169.254/metadata/v1/hostname)
export PUBLIC_IPV4=$(curl -s http://169.254.169.254/metadata/v1/interfaces/public/0/ipv4/address)
echo Droplet: $HOSTNAME, IP Address: $PUBLIC_IPV4 > /usr/share/nginx/html/index.html

This user data will install Nginx and replace the contents of index.html with the droplet’s hostname and IP address (by referencing the Metadata service). Accessing either Droplet via its public IP address will show a basic webpage with the Droplet hostname and IP address, which will be useful for testing which Droplet the Reserved IP is pointing to at any given moment.

Create a Reserved IP

In the DigitalOcean Control Panel, click Networking, in the top menu, then Reserved IPs in the side menu.

No Reserved IPs

Assign a Reserved IP to your primary Droplet, then click the Assign Reserved IP button.

After the Reserved IP has been assigned, take a note of its IP address. Check that you can reach the Droplet that it was assigned to by visiting the Reserved IP address in a web browser.

http://your_reserved_ip

You should see the index page of your primary Droplet.

Configure DNS (Optional)

If you want to be able to access your HA setup via a domain name, go ahead and create an A record in your DNS that points your domain to your Reserved IP address. If your domain is using DigitalOcean’s nameservers, follow step three of the How To Set Up a Host Name with DigitalOcean tutorial. Once that propagates, you may access your active server via the domain name.

The example domain name we’ll use is example.com. If you don’t have a domain name to use right now, you will use the Reserved IP address to access your setup instead.

Configure Time Synchronization

Whenever you have multiple servers communicating with each other, especially with clustering software, it is important to ensure their clocks are synchronized. We’ll use NTP (Network Time Protocol) to synchronize our servers.

On both servers, use this command to open a time zone selector:

  1. sudo dpkg-reconfigure tzdata

Select your desired time zone. For example, we’ll choose America/New_York.

Next, update apt-get:

  1. sudo apt-get update

Then install the ntp package with this command;

  1. sudo apt-get -y install ntp

Your server clocks should now be synchronized using NTP. To learn more about NTP, check out this tutorial: Configure Timezones and Network Time Protocol Synchronization.

Configure Firewall

Corosync uses UDP transport between ports 5404 and 5406. If you are running a firewall, ensure that communication on those ports are allowed between the servers.

For example, if you’re using iptables, you could allow traffic on these ports and eth1 (the private network interface) with these commands:

  1. sudo iptables -A INPUT -i eth1 -p udp -m multiport --dports 5404,5405,5406 -m conntrack --ctstate NEW,ESTABLISHED -j ACCEPT
  2. sudo iptables -A OUTPUT -o eth1 -p udp -m multiport --sports 5404,5405,5406 -m conntrack --ctstate ESTABLISHED -j ACCEPT

It is advisable to use firewall rules that are more restrictive than the provided example.

Install Corosync and Pacemaker

On both servers, install Corosync and Pacemaker using apt-get:

  1. sudo apt-get install pacemaker

Note that Corosync is installed as a dependency of the Pacemaker package.

Corosync and Pacemaker are now installed but they need to be configured before they will do anything useful.

Configure Corosync

Corosync must be configured so that our servers can communicate as a cluster.

Create Cluster Authorization Key

In order to allow nodes to join a cluster, Corosync requires that each node possesses an identical cluster authorization key.

On the primary server, install the haveged package:

  1. sudo apt-get install haveged

This software package allows us to easily increase the amount of entropy on our server, which is required by the corosync-keygen script.

On the primary server, run the corosync-keygen script:

  1. sudo corosync-keygen

This will generate a 128-byte cluster authorization key, and write it to /etc/corosync/authkey.

Now that we no longer need the haveged package, let’s remove it from the primary server:

  1. sudo apt-get remove --purge haveged
  2. sudo apt-get clean

On the primary server, copy the authkey to the secondary server:

  1. sudo scp /etc/corosync/authkey username@secondary_ip:/tmp

On the secondary server, move the authkey file to the proper location, and restrict its permissions to root:

  1. sudo mv /tmp/authkey /etc/corosync
  2. sudo chown root: /etc/corosync/authkey
  3. sudo chmod 400 /etc/corosync/authkey

Now both servers should have an identical authorization key in the /etc/corosync/authkey file.

Configure Corosync Cluster

In order to get our desired cluster up and running, we must set up these

On both servers, open the corosync.conf file for editing in your favorite editor (we’ll use vi):

  1. sudo vi /etc/corosync/corosync.conf

Here is a Corosync configuration file that will allow your servers to communicate as a cluster. Be sure to replace the highlighted parts with the appropriate values. bindnetaddr should be set to the private IP address of the server you are currently working on. The two other highlighted items should be set to the indicated server’s private IP address. With the exception of the bindnetaddr, the file should be identical on both servers.

Replace the contents of corosync.conf with this configuration, with the changes that are specific to your environment:

/etc/corosync/corosync.conf
  1. totem {
  2. version: 2
  3. cluster_name: lbcluster
  4. transport: udpu
  5. interface {
  6. ringnumber: 0
  7. bindnetaddr: server_private_IP_address
  8. broadcast: yes
  9. mcastport: 5405
  10. }
  11. }
  12. quorum {
  13. provider: corosync_votequorum
  14. two_node: 1
  15. }
  16. nodelist {
  17. node {
  18. ring0_addr: primary_private_IP_address
  19. name: primary
  20. nodeid: 1
  21. }
  22. node {
  23. ring0_addr: secondary_private_IP_address
  24. name: secondary
  25. nodeid: 2
  26. }
  27. }
  28. logging {
  29. to_logfile: yes
  30. logfile: /var/log/corosync/corosync.log
  31. to_syslog: yes
  32. timestamp: on
  33. }

The totem section (lines 1-11), which refers to the Totem protocol that Corosync uses for cluster membership, specifies how the cluster members should communicate with each other. In our setup, the important settings include transport: udpu (specifies unicast mode) and bindnetaddr (specifies which network address Corosync should bind to).

The quorum section (lines 13-16) specifies that this is a two-node cluster, so only a single node is required for quorum (two_node: 1). This is a workaround of the fact that achieving a quorum requires at least three nodes in a cluster. This setting will allow our two-node cluster to elect a coordinator (DC), which is the node that controls the cluster at any given time.

The nodelist section (lines 18-29) specifies each node in the cluster, and how each node can be reached. Here, we configure both our primary and secondary nodes, and specify that they can be reached via their respective private IP addresses.

The logging section (lines 31-36) specifies that the Corosync logs should be written to /var/log/corosync/corosync.log. If you run into any problems with the rest of this tutorial, be sure to look here while you troubleshoot.

Save and exit.

Next, we need to configure Corosync to allow the Pacemaker service.

On both servers, create the pcmk file in the Corosync service directory with an editor. We’ll use vi:

  1. sudo vi /etc/corosync/service.d/pcmk

Then add the Pacemaker service:

service {
  name: pacemaker
  ver: 1
}

Save and exit. This will be included in the Corosync configuration, and allows Pacemaker to use Corosync to communicate with our servers.

By default, the Corosync service is disabled. On both servers, change that by editing /etc/default/corosync:

  1. sudo vi /etc/default/corosync

Change the value of START to yes:

/etc/default/corosync
START=yes

Save and exit. Now we can start the Corosync service.

On both servers, start Corosync with this command:

  1. sudo service corosync start

Once Corosync is running on both servers, they should be clustered together. We can verify this by running this command:

  1. sudo corosync-cmapctl | grep members

The output should look something like this, which indicates that the primary (node 1) and secondary (node 2) have joined the cluster:

corosync-cmapctl output:
runtime.totem.pg.mrp.srp.members.1.config_version (u64) = 0 runtime.totem.pg.mrp.srp.members.1.ip (str) = r(0) ip(primary_private_IP_address) runtime.totem.pg.mrp.srp.members.1.join_count (u32) = 1 runtime.totem.pg.mrp.srp.members.1.status (str) = joined runtime.totem.pg.mrp.srp.members.2.config_version (u64) = 0 runtime.totem.pg.mrp.srp.members.2.ip (str) = r(0) ip(secondary_private_IP_address) runtime.totem.pg.mrp.srp.members.2.join_count (u32) = 1 runtime.totem.pg.mrp.srp.members.2.status (str) = joined

Now that you have Corosync set up properly, let’s move onto configuring Pacemaker.

Start and Configure Pacemaker

Pacemaker, which depends on the messaging capabilities of Corosync, is now ready to be started and to have its basic properties configured.

Enable and Start Pacemaker

The Pacemaker service requires Corosync to be running, so it is disabled by default.

On both servers, enable Pacemaker to start on system boot with this command:

  1. sudo update-rc.d pacemaker defaults 20 01

With the prior command, we set Pacemaker’s start priority to 20. It is important to specify a start priority that is higher than Corosync’s (which is 19 by default), so that Pacemaker starts after Corosync.

Now let’s start Pacemaker:

  1. sudo service pacemaker start

To interact with Pacemaker, we will use the crm utility.

Check Pacemaker with crm:

  1. sudo crm status

This should output something like this (if not, wait for 30 seconds, then run the command again):

crm status:
Last updated: Fri Oct 16 14:38:36 2015 Last change: Fri Oct 16 14:36:01 2015 via crmd on primary Stack: corosync Current DC: primary (1) - partition with quorum Version: 1.1.10-42f2063 2 Nodes configured 0 Resources configured Online: [ primary secondary ]

There are a few things to note about this output. First, Current DC (Designated Coordinator) should be set to either primary (1) or secondary (2). Second, there should be 2 Nodes configured and 0 Resources configured. Third, both nodes should be marked as online. If they are marked as offline, try waiting 30 seconds and check the status again to see if it corrects itself.

From this point on, you may want to run the interactive CRM monitor in another SSH window (connected to either cluster node). This will give you real-time updates of the status of each node, and where each resource is running:

  1. sudo crm_mon

The output of this command looks identical to the output of crm status except it runs continuously. If you want to quit, press Ctrl-C.

Configure Cluster Properties

Now we’re ready to configure the basic properties of Pacemaker. Note that all Pacemaker (crm) commands can be run from either node server, as it automatically synchronizes all cluster-related changes across all member nodes.

For our desired setup, we want to disable STONITH—a mode that many clusters use to remove faulty nodes—because we are setting up a two-node cluster. To do so, run this command on either server:

  1. sudo crm configure property stonith-enabled=false

We also want to disable quorum-related messages in the logs:

  1. sudo crm configure property no-quorum-policy=ignore

Again, this setting only applies to 2-node clusters.

If you want to verify your Pacemaker configuration, run this command:

  1. sudo crm configure show

This will display all of your active Pacemaker settings. Currently, this will only include two nodes, and the STONITH and quorum properties you just set.

Create Reserved IP Reassignment Resource Agent

Now that Pacemaker is running and configured, we need to add resources for it to manage. As mentioned in the introduction, resources are services that the cluster is responsible for making highly available. In Pacemaker, adding a resource requires the use of a resource agent, which act as the interface to the service that will be managed. Pacemaker ships with several resource agents for common services, and allows custom resource agents to be added.

In our setup, we want to make sure that the service provided by our web servers, primary and secondary, is highly available in an active/passive setup, which means that we need a way to ensure that our Reserved IP is always pointing to a server that is available. To enable this, we need to set up a resource agent that each node can run to determine if it owns the Reserved IP and, if necessary, run a script to point the Reserved IP to itself. Reserved IPs are sometimes known as floating IPs. In the following examples, we’ll refer to the resource agent as “FloatIP OCF”, and the Reserved IP reassignment script as assign-ip. Once we have the FloatIP OCF resource agent installed, we can define the resource itself, which we’ll refer to as FloatIP.

Download assign-ip Script

As we just mentioned, we need a script that can reassign which Droplet our Reserved IP is pointing to, in case the FloatIP resource needs to be moved to a different node. For this purpose, we’ll download a basic Python script that assigns a Reserved IP to a given Droplet ID, using the DigitalOcean API.

On both servers, download the assign-ip Python script:

  1. sudo curl -L -o /usr/local/bin/assign-ip http://do.co/assign-ip

On both servers, make it executable:

  1. sudo chmod +x /usr/local/bin/assign-ip

Use of the assign-ip script requires the following details:

  • Reserved IP: The first argument to the script, the Reserved IP that is being assigned
  • Droplet ID: The second argument to the script, the Droplet ID that the Reserved IP should be assigned to
  • DigitalOcean PAT (API token): Passed in as the environment variable DO_TOKEN, your read/write DigitalOcean PAT

Feel free to review the contents of the script before continuing.

So, if you wanted to manually run this script to reassign a Reserved IP, you could run it like so: DO_TOKEN=your_digitalocean_pat /usr/local/bin/assign-ip your_reserved_ip droplet_id. However, this script will be invoked from the FloatIP OCF resource agent in the event that the FloatIP resource needs to be moved to a different node.

Let’s install the Float IP Resource Agent next.

Download FloatIP OCF Resource Agent

Pacemaker allows the addition of OCF resource agents by placing them in a specific directory.

On both servers, create the digitalocean resource agent provider directory with this command:

  1. sudo mkdir /usr/lib/ocf/resource.d/digitalocean

On both servers, download the FloatIP OCF Resource Agent:

  1. sudo curl -o /usr/lib/ocf/resource.d/digitalocean/floatip https://gist.githubusercontent.com/thisismitch/b4c91438e56bfe6b7bfb/raw/2dffe2ae52ba2df575baae46338c155adbaef678/floatip-ocf

On both servers, make it executable:

  1. sudo chmod +x /usr/lib/ocf/resource.d/digitalocean/floatip

Feel free to review the contents of the resource agent before continuing. It is a bash script that, if called with the start command, will look up the Droplet ID of the node that calls it (via Metadata), and assign the Reserved IP to the Droplet ID. Also, it responds to the status and monitor commands by returning whether the calling Droplet has a Reserved IP assigned to it.

It requires the following OCF parameters:

  • do_token:: The DigitalOcean API token to use for Reserved IP reassignments, i.e. your DigitalOcean Personal Access Token
  • reserved_ip:: Your Reserved IP (address), in case it needs to be reassigned

Now we can use the FloatIP OCF resource agent to define our FloatIP resource.

Add FloatIP Resource

With our FloatIP OCF resource agent installed, we can now configure our FloatIP resource.

On either server, create the FloatIP resource with this command (be sure to specify the two highlighted parameters with your own information):

  1. sudo crm configure primitive FloatIP ocf:digitalocean:floatip \
  2. params do_token=your_digitalocean_personal_access_token \
  3. reserved_ip=your_reserved_ip

This creates a primitive resource, which is a generic type of cluster resource, called “FloatIP”, using the FloatIP OCF Resource Agent we created earlier (ocf:digitalocean:floatip). Notice that it requires the do_token and reserved_ip to be passed as parameters. These will be used if the Reserved IP needs to be reassigned.

If you check the status of your cluster (sudo crm status or sudo crm_mon), you should see that the FloatIP resource is defined and started on one of your nodes:

crm_mon:
... 2 Nodes configured 1 Resource configured Online: [ primary secondary ] FloatIP (ocf::digitalocean:floatip): Started primary

Assuming that everything was set up properly, you should now have an active/passive HA setup! As it stands, the Reserved IP will get reassigned to an online server if the node that the FloatIP is started on goes offline or into standby mode. Right now, if the active node—primary, in our example output—becomes unavailable, the cluster will instruct the secondary node to start the FloatIP resource and claim the Reserved IP address for itself. Once the reassignment occurs, the Reserved IP will direct users to the newly active secondary server.

Currently, the failover (Reserved IP reassignment) is only triggered if the active host goes offline or is unable to communicate with the cluster. A better version of this setup would specify additional resources that should be managed by Pacemaker. This would allow the cluster to detect failures of specific services, such as load balancer or web server software. Before setting that up, though, we should make sure the basic failover works.

Test High Availability

It’s important to test that our high availability setup works, so let’s do that now.

Currently, the Reserved IP is assigned to the one of your nodes (let’s assume primary). Accessing the Reserved IP now, via the IP address or by the domain name that is pointing to it, will simply show the index page of the primary server. If you used the example user data script, it will look something like this:

Reserved IP is pointing to primary server:
Droplet: primary, IP Address: primary_ip_address

This indicates that the Reserved IP is, in fact, assigned to the primary Droplet.

Now, let’s open a new local terminal and use curl to access the Reserved IP on a 1 second loop. Use this command to do so, but be sure to replace the URL with your domain or Reserved IP address:

  1. while true; do curl reserved_IP_address; sleep 1; done

Currently, this will output the same Droplet name and IP address of the primary server. If we cause the primary server to fail, by powering it off or by changing the primary node’s cluster status to standby, we will see if the Reserved IP gets reassigned to the secondary server.

Let’s reboot the primary server now. Do so via the DigitalOcean Control Panel or by running this command on the primary server:

  1. sudo reboot

After a few moments, the primary server should become unavailable. Pay attention to the output of the curl loop that is running in the terminal. You should notice output that looks like this:

curl loop output:
Droplet: primary, IP Address: primary_IP_address ... curl: (7) Failed to connect to reserved_IP_address port 80: Connection refused Droplet: secondary, IP Address: secondary_IP_address ...

That is, the Reserved IP address should be reassigned to point to the IP address of the secondary server. That means that your HA setup is working, as a successful automatic failover has occurred.

You may or may not see the Connection refused error, which can occur if you try and access the Reserved IP between the primary server failure and the Reserved IP reassignment completion.

If you check the status of Pacemaker, you should see that the FloatIP resource is started on the secondary server. Also, the primary server should temporarily be marked as OFFLINE but will join the Online list as soon as it completes its reboot and rejoins the cluster.

Troubleshooting the Failover (Optional)

Skip this section if your HA setup works as expected. If the failover did not occur as expected, you should review your setup before moving on. In particular, make sure that any references to your own setup, such as node IP addresses, your Reserved IP, and your API token.

Useful Commands for Troubleshooting

Here are some commands that can help you troubleshoot your setup.

As mentioned earlier, the crm_mon tool can be very helpful in viewing the real-time status of your nodes and resources:

  1. sudo crm_mon

Also, you can look at your cluster configuration with this command:

  1. sudo crm configure show

If the crm commands aren’t working at all, you should look at the Corosync logs for clues:

  1. sudo tail -f /var/log/corosync/corosync.log

Miscellaneous CRM Commands

These commands can be useful when configuring your cluster.

You can set a node to standby mode, which can be used to simulate a node becoming unavailable, with this command:

  1. sudo crm node standby NodeName

You can change a node’s status from standby to online with this command:

  1. sudo crm node online NodeName

You can edit a resource, which allows you to reconfigure it, with this command:

sudo crm configure edit ResourceName

You can delete a resource, which must be stopped before it is deleted, with these command:

  1. sudo crm resource stop ResourceName
  2. sudo crm configure delete ResourceName

Lastly, the crm command can be run by itself to access an interactive crm prompt:

  1. crm

We won’t cover the usage of the interactive crm prompt, but it can be used to do all of the crm configuration we’ve done up to this point.

Add Nginx Resource (optional)

Now that you are sure that your Reserved IP failover works, let’s look into adding a new resource to your cluster. In our example setup, Nginx is the main service that we are making highly available, so let’s work on adding it as a resource that our cluster will manage.

Pacemaker comes with an Nginx resource agent, so we can easily add Nginx as a cluster resource.

Use this command to create a new primitive cluster resource called “Nginx”:

  1. sudo crm configure primitive Nginx ocf:heartbeat:nginx \
  2. params httpd="/usr/sbin/nginx" \
  3. op start timeout="40s" interval="0" \
  4. op monitor timeout="30s" interval="10s" on-fail="restart" \
  5. op stop timeout="60s" interval="0"

The specified resource tells the cluster to monitor Nginx every 10 seconds, and to restart it if it becomes unavailable.

Check the status of your cluster resources by using sudo crm_mon or sudo crm status:

crm_mon:
... Online: [ primary secondary ] FloatIP (ocf::digitalocean:floatip): Started primary Nginx (ocf::heartbeat:nginx): Started secondary

Unfortunately, Pacemaker will decide to start the Nginx and FloatIP resources on separate nodes because we have not defined any resource constraints. This is a problem because this means that the Reserved IP will be pointing to one Droplet, while the Nginx service will only be running on the other Droplet. Accessing the Reserved IP will point you to a server that is not running the service that should be highly available.

To resolve this issue, we’ll create a clone resource, which specifies that an existing primitive resource should be started on multiple nodes.

Create a clone resource of the Nginx resource called “Nginx-clone” with this command:

  1. sudo crm configure clone Nginx-clone Nginx

The cluster status should now look something like this:

crm_mon:
Online: [ primary secondary ] FloatIP (ocf::digitalocean:floatip): Started primary Clone Set: Nginx-clone [Nginx] Started: [ primary secondary ]

As you can see, the clone resource, Nginx-clone, is now started on both of our nodes.

The last step is to configure a colocation restraint, to specify that the FloatIP resource should run on a node with an active Nginx-clone resource. To create a colocation restraint called “FloatIP-Nginx”, use this command:

  1. sudo crm configure colocation FloatIP-Nginx inf: FloatIP Nginx-clone

You won’t see any difference in the crm status output, but you can see that the colocation resource was created with this command:

  1. sudo crm configure show

Now, both of your servers should have Nginx running, while only one of them has the FloatIP resource running. Now is a good time to test your HA setup by stopping your Nginx service and by rebooting or powering off your active server.

Conclusion

Congratulations! You now have a basic HA server setup using Corosync, Pacemaker, and a DigitalOcean Reserved IP.

The next step is to replace the example Nginx setup with a reverse-proxy load balancer. You can use Nginx or HAProxy for this purpose. Keep in mind that you will want to bind your load balancer to the anchor IP address, so that your users can only access your servers via the Reserved IP address (and not via the public IP address of each server). This process is detailed in the How To Create a High Availability HAProxy Setup with Corosync, Pacemaker, and Reserved IPs on Ubuntu 14.04 tutorial.

Thanks for learning with the DigitalOcean Community. Check out our offerings for compute, storage, networking, and managed databases.

Learn more about our products

About the authors

Still looking for an answer?

Ask a questionSearch for more help

Was this helpful?

10 Comments


This textbox defaults to using Markdown to format your answer.

You can type !ref in this text area to quickly search our full set of tutorials, documentation & marketplace offerings and insert the link!

Hey Guys, Thanks for this tutorial, I’ve followed it and works a treat if I reboot server1 - server2 presents the web using the floating IP. However after following the steps for Nginx I don’t get the same results instead the server starts up the Nginx process on server1. I really want it to fail over to server2 and the n restart Nginx - can this be done? Thanks

In the /etc/default/corosync file, I followed the instructions and wrote the private IP addresses. Yet, the output of sudo crm status shows that there is only one node “the primary server”:

Cluster Summary:
  * Stack: corosync
  * Current DC: ip-<private ip of primary server> (version 2.1.2-ada5c3b36e2) - partition with quorum
  * Last updated: Wed Jul 20 10:56:41 2022
  * Last change:  Wed Jul 20 10:40:16 2022 by hacluster via crmd on ip-<private ip of primary server>
  * 1 node configured
  * 0 resource instances configured

Node List:
  * Online: [ ip-<private ip of primary server> ]

Full List of Resources:
  * No resources

I don’t understand why it doesn’t see the secondary server. Any help?

Hello. I have a question. I wrote down the text. First, I would like to know about the configurable scope of ha cluster (pacemaker, corosync, pcs). Can you adjust the time when the primary is down and moving on to the secondary? And can monitoring tools such as nagios and zabbix be implanted into the ha cluster?

Hi again folks, I’m sorry for being noisy.

This guide is as always, great, but I’m having a small problem with Floating IP assigning.

In the console using sudo crm status or sudo crm_mon, everything looks fine. The floating automatically change “starting node” like this:* Started sh-ps-01* However… The changes in the console do not reflect on the Floating IP itself.

I go to the floating IP when server 1 is online. I shutdown server 1 using sudo shutdown, in the console. The console on server 2 will change it to Started sh-ps-02 after a few seconds after it lost connection to server 1… If I then browse to the FloatingIP in the web browser, it will get errors. When I manually assign it to the droplet, it works.

Any ideas what is going on?

Hi!

I’ve followed this guide to get two node working, but in my crm status it shows as 3 node.

quorum { provider: corosync_votequorum two_node: 1 }

output:

sudo crm status Last updated: Tue Mar 27 10:15:14 2018 Last change: Tue Mar 27 10:05:57 2018 by root via cibadmin on primary Stack: corosync Current DC: secondary (version 1.1.14-70404b0) - partition with quorum 3 nodes and 1 resource configured

Online: [ secondary ] OFFLINE: [ primary sh-lb-02 ]

Full list of resources:

FloatIP (ocf::digitalocean:floatip): Started secondary

any idea why it says 3node? I also noticed this part: Online: [ secondary ] OFFLINE: [ primary sh-lb-02 ]

sh-lb-02 is the name of the secondary… x)

I started up the primary again: Online: [ primary secondary ] OFFLINE: [ sh-lb-02 ]

Hi, how can i generate bindnetaddr ?

Great howto. Can this setup be used for highly available NFS servers? Or would this only work with stateless applications?

Would there be any updated version of this great guide for Ubuntu 16.04? Globally it seems to work fine, but the /etc/corosync/service.d/ directory doesn’t exist by default and I’m not convinced that it should be created there (or if the pcmk service definition should rather be included in the corosync.conf file as a new block or something like that).

Also, given you have a cluster and unless you put a firewall between the load balancers and your web servers, you could very well use the web servers as cluster members (nodes) without giving them any resource. This would make your cluster more reliable because you would have more nodes able to “vote” in the quorum (but I understand that for the specific goal of this guide, it might be better not to include them).

Hello,

I have to disable my firewall by “sudo ufw disable” to make it work. How can I instead add an exception in ufw?

I have followed the tutorial step by step and confirmed all IP addresses multiple times. When I execute crm status I get the following output, which seems fine to me:

Stack: corosync
Current DC: secondary (version 1.1.14-70404b0) - partition with quorum
2 nodes and 1 resource configured

Online: [ primary secondary ]

Full list of resources:

 FloatIP	(ocf::digitalocean:floatip):	Started primary

However, when I try to test if everything is working by curling for while true; do curl my.floating.ipaddress; sleep 1; done I get output with the droplet name and IP address of my primary node. If I reboot the primary node, the curl “hangs” until the primary node starts, then again prints out droplet name and IP address of the primary node (instead of switching to secondary immediately), an indicator that the redirecting of IP addresses is not working.

If I then check the crm status again however, the status shows that a switch to the secondary node has been performed:

Stack: corosync
Current DC: secondary (version 1.1.14-70404b0) - partition with quorum
2 nodes and 1 resource configured

Online: [ primary secondary ]

Full list of resources:

 FloatIP	(ocf::digitalocean:floatip):	Started secondary

Can anybody tell me what could be wrong with my setup?

crm configure show prints the following:

node 1: primary
node 2: secondary
primitive FloatIP ocf:digitalocean:floatip \
	params do_token=my_access_token floating_ip=my.floating.ipaddress
property cib-bootstrap-options: \
	have-watchdog=false \
	dc-version=1.1.14-70404b0 \
	cluster-infrastructure=corosync \
	cluster-name=lbcluster \
	stonith-enabled=false \
	no-quorum-policy=ignore

Try DigitalOcean for free

Click below to sign up and get $200 of credit to try our products over 60 days!

Sign up

Join the Tech Talk
Success! Thank you! Please check your email for further details.

Please complete your information!

Featured on Community

Get our biweekly newsletter

Sign up for Infrastructure as a Newsletter.

Hollie's Hub for Good

Working on improving health and education, reducing inequality, and spurring economic growth? We'd like to help.

Become a contributor

Get paid to write technical tutorials and select a tech-focused charity to receive a matching donation.

Welcome to the developer cloud

DigitalOcean makes it simple to launch in the cloud and scale up as you grow — whether you're running one virtual machine or ten thousand.

Learn more
