Set Up and Configure an Application Server on Ubuntu 24.04

• Configure a production-ready application server on Ubuntu 24.04 using a DigitalOcean Droplet.
• Set up Nginx as a reverse proxy to handle incoming requests and route traffic to your applications
• Implement SSL/TLS encryption using Let’s Encrypt for secure connections.
• Deploy and manage applications using systemd for reliable process management.
• Apply security hardening measures including firewall configuration and user permissions.
• Support multiple application types including Node.js, Python, and PHP applications.

Before you begin, ensure you have the following:

• A DigitalOcean Droplet running Ubuntu 24.04. If you need to create one, follow our guide on Initial Server Setup with Ubuntu, which includes creating a non-root user with sudo privileges and configuring a firewall.
• A domain name pointed to your Droplet’s IP address. You can configure this by following our guide on How to Set Up a Host Name with DigitalOcean.
• Basic familiarity with the Linux command line and SSH access to your server.

Start by updating your system’s package index and upgrading existing packages to ensure you have the latest security patches and software versions:

sudo apt update
sudo apt upgrade -y

This ensures your Ubuntu 24.04 server has the most recent package information and security updates. Ubuntu 24.04 includes updated package versions compared to Ubuntu 22.04, including newer versions of systemd, Nginx, and other core components.

Nginx serves as a reverse proxy, handling incoming HTTP and HTTPS requests and forwarding them to your application server. This setup provides several benefits: SSL termination, load balancing capabilities, and improved security by keeping your application server behind the proxy.

Install Nginx using apt:

sudo apt install nginx -y

After installation, start and enable Nginx to run automatically on boot:

sudo systemctl start nginx
sudo systemctl enable nginx

Verify that Nginx is running:

sudo systemctl status nginx

You should see output indicating that Nginx is active and running.

Output
● nginx.service - A high performance web server and a reverse proxy server
     Loaded: loaded (/usr/lib/systemd/system/nginx.service; enabled; preset: enabled)
     Active: active (running) since Thu 2025-12-18 07:03:01 UTC; 32s ago
       Docs: man:nginx(8)
   Main PID: 46284 (nginx)
      Tasks: 3 (limit: 4656)
     Memory: 2.4M (peak: 5.3M)
        CPU: 46ms
     CGroup: /system.slice/nginx.service
             ├─46284 "nginx: master process /usr/sbin/nginx -g daemon on; master_process on;"
             ├─46286 "nginx: worker process"
             └─46287 "nginx: worker process"

Dec 18 07:03:01 Anish-Ubuntu-24 systemd[1]: Starting nginx.service - A high performance web server and a reverse proxy server...
Dec 18 07:03:01 Anish-Ubuntu-24 systemd[1]: Started nginx.service - A high performance web server and a reverse proxy server.

Ubuntu 24.04 uses UFW (Uncomplicated Firewall) for firewall management. Configure it to allow HTTP, HTTPS, and SSH traffic while blocking other unnecessary ports.

First, ensure UFW is installed and check its status:

sudo ufw status

If UFW is not active, enable it and configure the necessary rules:

sudo ufw allow OpenSSH
sudo ufw allow 'Nginx Full'
sudo ufw enable

Output
sudo ufw allow 'Nginx Full'
sudo ufw enable
Rules updated
Rules updated (v6)
Rules updated
Rules updated (v6)
Command may disrupt existing ssh connections. Proceed with operation (y|n)? y
Firewall is active and enabled on system startup

The Nginx Full profile allows both HTTP (port 80) and HTTPS (port 443) traffic. Verify the firewall rules:

sudo ufw status verbose

You should see rules allowing OpenSSH and Nginx Full traffic.

Output
Status: active
Logging: on (low)
Default: deny (incoming), allow (outgoing), disabled (routed)
New profiles: skip

To                         Action      From
--                         ------      ----
22/tcp (OpenSSH)           ALLOW IN    Anywhere
80,443/tcp (Nginx Full)    ALLOW IN    Anywhere
22/tcp (OpenSSH (v6))      ALLOW IN    Anywhere (v6)
80,443/tcp (Nginx Full (v6)) ALLOW IN    Anywhere (v6)

Securing your application server with SSL/TLS encryption is essential for production deployments. Let’s Encrypt provides free SSL certificates that can be automatically renewed.

Install Certbot and the Nginx plugin:

sudo apt install certbot python3-certbot-nginx -y

Obtain an SSL certificate for your domain. Replace your_domain with your actual domain name:

sudo certbot --nginx -d your_domain -d www.your_domain

Certbot will prompt you for an email address and ask whether you want to redirect HTTP traffic to HTTPS. Choose to redirect for better security. The certificate will be automatically renewed before expiration.

Test the automatic renewal process:

sudo certbot renew --dry-run

If this command completes without errors, automatic renewal is configured correctly.

Create an Nginx server block configuration to route traffic to your application server. This example shows a generic configuration that you can adapt for different application types.

Create a new configuration file for your domain:

sudo nano /etc/nginx/sites-available/your_domain

Add the following configuration, replacing your_domain with your actual domain and adjusting the proxy_pass URL to match your application’s port:

server {
    listen 80;
    listen [::]:80;
    server_name your_domain www.your_domain;

    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    listen [::]:443 ssl http2;
    server_name your_domain www.your_domain;

    ssl_certificate /etc/letsencrypt/live/your_domain/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/your_domain/privkey.pem;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        proxy_pass http://localhost:3000;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_cache_bypass $http_upgrade;
    }
}

This configuration:

• Redirects HTTP traffic to HTTPS
• Terminates SSL at the Nginx level
• Forwards requests to your application running on port 3000 (adjust as needed)
• Preserves client IP addresses and protocol information

Enable the configuration by creating a symbolic link:

sudo ln -s /etc/nginx/sites-available/your_domain /etc/nginx/sites-enabled/

Test the Nginx configuration for syntax errors:

sudo nginx -t

If the test passes, reload Nginx to apply the changes:

sudo systemctl reload nginx

The runtime dependencies you need depend on your application type. This section covers setup for Node.js, Python, and PHP applications.

Installing Node.js

For Node.js applications, install Node.js using NodeSource’s repository to get the latest LTS version:

curl -fsSL https://deb.nodesource.com/setup_20.x | sudo -E bash -
sudo apt install -y nodejs

Verify the installation:

node --version
npm --version

Output
v20.19.6
10.8.2

Installing Python and pip

Ubuntu 24.04 includes Python 3.12 by default. Install pip and virtual environment tools:

sudo apt install python3-pip python3-venv -y

Verify the installation:

python3 --version
pip3 --version

Output
pip3 --version
Python 3.12.3
pip 24.0 from /usr/lib/python3/dist-packages/pip (python 3.12)

Installing PHP and PHP-FPM

For PHP applications, install PHP and PHP-FPM (FastCGI Process Manager):

sudo apt install php-fpm php-mysql php-mbstring php-xml php-curl -y

Verify PHP-FPM is running:

sudo systemctl status php8.3-fpm

Output
 Loaded: loaded (/usr/lib/systemd/system/php8.3-fpm.service; enabled; preset: enabled)
     Active: active (running) since Thu 2025-12-18 08:02:36 UTC; 1min 56s ago
       Docs: man:php-fpm8.3(8)
    Process: 59077 ExecStartPost=/usr/lib/php/php-fpm-socket-helper install /run/php/php-fpm.sock /etc/php/8.3/fpm/pool.d/www.conf 83 (code=exited, >
   Main PID: 59074 (php-fpm8.3)
     Status: "Processes active: 0, idle: 2, Requests: 0, slow: 0, Traffic: 0req/sec"
      Tasks: 3 (limit: 4656)
     Memory: 9.5M (peak: 10.4M)
        CPU: 97ms
     CGroup: /system.slice/php8.3-fpm.service
             ├─59074 "php-fpm: master process (/etc/php/8.3/fpm/php-fpm.conf)"
             ├─59075 "php-fpm: pool www"
             └─59076 "php-fpm: pool www"

Dec 18 08:02:36 Anish-Ubuntu-24 systemd[1]: Starting php8.3-fpm.service - The PHP 8.3 FastCGI Process Manager...

<$> Note: Ubuntu 24.04 includes PHP 8.3. Adjust version numbers if your system uses a different version. <$>

Systemd manages your application as a service, ensuring it starts automatically on boot and restarts if it crashes. This example creates a systemd service for a Node.js application, but you can adapt it for other application types.

Create a systemd service file:

sudo nano /etc/systemd/system/your-app.service

Add the following configuration, adjusting paths and environment variables as needed:

[Unit]
Description=Your Application Server
After=network.target

[Service]
Type=simple
User=www-data
WorkingDirectory=/var/www/your-app
Environment="NODE_ENV=production"
Environment="PORT=3000"
ExecStart=/usr/bin/node /var/www/your-app/server.js
Restart=on-failure
RestartSec=10

[Install]
WantedBy=multi-user.target

Key configuration points:

• Type=simple: For applications that run in the foreground
• User=www-data: Runs the application as a non-root user for security
• WorkingDirectory: Sets the application’s working directory
• Restart=on-failure: Automatically restarts the application if it crashes
• RestartSec=10: Waits 10 seconds before restarting

Reload systemd and start your service:

sudo systemctl daemon-reload
sudo systemctl start your-app
sudo systemctl enable your-app

Check the service status:

sudo systemctl status your-app

Output
● your-app.service
     Loaded: loaded (/etc/systemd/system/your-app.service; enabled; preset: enabled)
     Active: active (running) since Thu 2025-12-18 08:07:30 UTC; 4ms ago
   Main PID: 59408 ((node))
      Tasks: 1 (limit: 4656)
     Memory: 512.0K (peak: 512.0K)
        CPU: 936us
     CGroup: /system.slice/your-app.service
             └─59408 "(node)"

Dec 18 08:07:30 Anish-Ubuntu-24 systemd[1]: your-app.service: Scheduled restart job, restart counter is at 4.
Dec 18 08:07:30 Anish-Ubuntu-24 systemd[1]: Started your-app.service.

Python Application Example

For a Python application using Gunicorn, your systemd service might look like this:

[Unit]
Description=Your Python Application
After=network.target

[Service]
Type=notify
User=www-data
WorkingDirectory=/var/www/your-app
Environment="PATH=/var/www/your-app/venv/bin"
ExecStart=/var/www/your-app/venv/bin/gunicorn --bind 127.0.0.1:8000 app:app
Restart=on-failure

[Install]
WantedBy=multi-user.target

PHP Application Example

For PHP applications, you typically use PHP-FPM with Nginx. Configure Nginx to pass requests to PHP-FPM:

location ~ \.php$ {
    include snippets/fastcgi-php.conf;
    fastcgi_pass unix:/var/run/php/php8.3-fpm.sock;
}

Create a directory for your application and set appropriate permissions:

sudo mkdir -p /var/www/your-app
sudo chown -R www-data:www-data /var/www/your-app

Deploy your application files to this directory. You can use Git, SCP, or other deployment methods:

cd /var/www/your-app
sudo -u www-data git clone https://github.com/your-username/your-repo.git .

Install dependencies and build your application as needed. For Node.js:

sudo -u www-data npm install --production

For Python:

sudo -u www-data python3 -m venv venv
sudo -u www-data ./venv/bin/pip install -r requirements.txt

After deploying, restart your application service:

sudo systemctl restart your-app

Apply these security measures to harden your application server for production use.

Disable Root Login via SSH

Edit the SSH configuration:

sudo nano /etc/ssh/sshd_config

Set the following:

PermitRootLogin no
PasswordAuthentication no

Restart SSH:

sudo systemctl restart sshd

Configure Automatic Security Updates

Enable automatic security updates:

sudo apt install unattended-upgrades -y
sudo dpkg-reconfigure -plow unattended-upgrades

Set Up Log Rotation

Configure log rotation to prevent log files from consuming disk space. Edit the logrotate configuration:

sudo nano /etc/logrotate.d/your-app

Add:

/var/www/your-app/logs/*.log {
    daily
    missingok
    rotate 14
    compress
    delaycompress
    notifempty
    create 0640 www-data www-data
    sharedscripts
}

Monitor Disk Space

Set up monitoring to alert you when disk space is low. Install and configure monitoring tools:

sudo apt install htop iotop -y

This section addresses common problems you might encounter when setting up your application server.

Application Not Starting

Check the service status and logs:

sudo systemctl status your-app
sudo journalctl -u your-app -n 50 --no-pager

Common issues include:

• Incorrect file paths in the systemd service file
• Missing environment variables
• Permission errors (ensure the service user can access application files)

Nginx 502 Bad Gateway Error

This usually means Nginx cannot connect to your application. Check:

• Your application is running:

sudo systemctl status your-app

• The application is listening on the correct port:

sudo netstat -tlnp | grep 3000

• The proxy_pass URL in your Nginx configuration matches your application’s port.

SSL Certificate Issues

If SSL certificates fail to renew:

• Check Certbot logs:

sudo tail -f /var/log/letsencrypt/letsencrypt.log

• Verify your domain’s DNS records point to your server:

dig your_domain

• Ensure ports 80 and 443 are open in your firewall.

High Memory Usage

Monitor memory usage:

free -h
htop

If your application consumes too much memory, consider:

• Optimizing your application code
• Increasing your Droplet’s RAM
• Implementing application-level caching

1. What is an application server in Ubuntu?

An application server is a server environment that runs and manages web applications. On Ubuntu 24.04, this typically involves configuring a runtime environment (like Node.js, Python, or PHP), setting up a reverse proxy (like Nginx), and using systemd to manage application processes. The application server handles incoming requests, executes application code, and returns responses to clients.

2. How do I configure systemd for my app?

To configure systemd for your application, you’ll need to create a service file. Here’s a step-by-step example:

Suppose your application is a Node.js app located at /home/ubuntu/my-app, and you want to run it with npm start using the ubuntu user.

• Create the systemd service file:

sudo nano /etc/systemd/system/my-app.service

• Add the following content to the file:

[Unit]
Description=My Node.js App
After=network.target

[Service]
Type=simple
User=ubuntu
WorkingDirectory=/home/ubuntu/my-app
ExecStart=/usr/bin/npm start
Restart=on-failure
Environment=NODE_ENV=production

[Install]
WantedBy=multi-user.target

• Reload systemd to recognize the new service:

sudo systemctl daemon-reload

• Enable the service to start on boot:

sudo systemctl enable my-app

• Start the application:

sudo systemctl start my-app

Now, your app will run in the background, restart on failure, and automatically start at boot. You can check its status with:

sudo systemctl status my-app

This method works with most applications. Just adjust the ExecStart, User, and WorkingDirectory as needed for your stack.

3. Should I use Nginx or Apache for my reverse proxy?

Both Nginx and Apache work well as reverse proxies, but Nginx is often preferred for modern application servers due to its lower memory footprint, better performance under high concurrency, and simpler configuration for reverse proxy scenarios.

Nginx also excels at handling static content and proxying requests to application servers, making it ideal for production deployments. Apache remains a solid choice, especially if you need specific modules or are more familiar with its configuration syntax.

4. How do I secure my application server on Ubuntu 24.04?

Secure your application server by: enabling UFW firewall and allowing only necessary ports, installing SSL certificates with Let’s Encrypt, running applications as non-root users, disabling root SSH login, configuring automatic security updates, keeping software packages updated, and implementing proper file permissions. Additionally, use strong passwords or SSH keys, configure fail2ban to prevent brute-force attacks, and regularly review application and system logs for suspicious activity.

5. Can I host multiple apps on a single Ubuntu server?

Yes, you can host multiple applications on a single Ubuntu 24.04 server. Configure separate systemd services for each application, each listening on different ports (e.g., 3000, 3001, 8000). Set up Nginx server blocks (virtual hosts) for each domain or subdomain, with each block proxying to the appropriate application port. This approach allows you to efficiently use server resources while maintaining isolation between applications.

6. How do I check if my app is running correctly?

Verify your application is running by checking the systemd service status with sudo systemctl status your-app. Review application logs using sudo journalctl -u your-app -f to see real-time log output. Test the application by accessing it through your domain or IP address. Check that Nginx is routing requests correctly by reviewing Nginx access and error logs at /var/log/nginx/access.log and /var/log/nginx/error.log. Monitor resource usage with htop or free -h to ensure your application isn’t consuming excessive CPU or memory.

You’ve successfully set up and configured a production ready application server on Ubuntu 24.04. Your DigitalOcean Droplet is now equipped with Nginx as a reverse proxy, SSL/TLS encryption, systemd service management, and security hardening measures. This setup supports deploying Node.js, Python, PHP, and other web applications in a secure, scalable environment.

The configuration follows production best practices, including automatic service restarts, SSL certificate renewal, firewall protection, and proper user permissions. Your application server is ready to handle real-world workloads and can be scaled as your needs grow.

For further learning and advanced configurations, explore these related DigitalOcean tutorials:

• How to Install and Use Docker on Ubuntu - Learn containerization for easier application deployment and management
• How to Configure Nginx as a Reverse Proxy on Ubuntu - Deep dive into advanced Nginx reverse proxy configurations
• Recommended Security Measures to Protect Your Servers - Additional security hardening techniques for production servers

Ready to deploy your applications? Get started with DigitalOcean Droplets to create scalable, reliable infrastructure for your application server. With features like automated backups, monitoring, and flexible pricing, DigitalOcean Droplets provide the foundation you need for production deployments.
